GW Instek AFG-3022 20MHz Dual Channel Arbitrary Function Generator

GW Instek AFG-3022 20MHz Dual Channel Arbitrary Function Generator

============================================================

Features

·         1uHz to 20 or 30MHz, 16-bit resolution with 1 mVpp to 10 Vpp amplitude. 1 or 2 channel (s)

·         250 MSa/s sampling rate for higher time resolution arbitrary waveforms

·         8M Points/channel standard waveform memory

·         Input/output signal ground independent of housing and signal ground between channels also insulated.

·         Synchronized phase operates up to 6 units and 12 channels

·         Pulse waveform parameters can be set independently for more precise timing

·         Harmonic signal generator

·         Dual channel models support SUM modulation, coupling, tracking, and phase functions

============================================================

Specifications

CHANNELS : 2

ARBITRARY WAVEFORMS

*Sample Rate : 250 MSa/s

*Repetition Rate : 125MHz

*Waveform Length : 8M points

FREQUENCY CHARACTERISTICS

*Sine/Square : 1µHz – 20MHz

*Pulse : 1µHz – 20MHz

NOISE

*Noise Type : Gaussian

*Noise Bandwidth : 100MHz equivalent bandwidth

HARMONIC

*Harmonic Order : ≤8

*Harmonic Type : Even, Odd, All, User; Amplitude and Phase can be set for all harmonics

DISPLAY : 4.3 inch TFT LCD, 480 x 3 (RGB) x 272

INTERFACE : LAN, USB

AC POWER INPUT : AC 100V - 240V, 50/60Hz, 50VA

DIMENSION & WEIGHT : 265 (W) x 107 (H) x 374 (D); Approx. 4kg

ACCESSORIES : Quick Start Guide x 1, CD-ROM with AFG software and user manual x 1, GTL-101, BNC Alligator Test Lead x 2 (only AFG-3032/AFG-3022)

===========================================================
