GW Instek GDS-1104B 100MHz, 4-Channel Digital Storage Oscilloscope

GW Instek GDS-1104B 100MHz, 4-Channel Digital Storage Oscilloscope

============================================================

Features

·         100MHz bandwidth selections, 4ch input

·         1GSa/s maximum sampling rate

·         10M maximum memory depth for each channel

·         I2C/SPI/UART/CAN/LIN serial bus trigger and decoding functions

·         1Mpts FFT frequency domain signal display

·         Zero Key function for horizontal time, vertical voltage and triggering

·         Compact and innovative exterior design

============================================================

Specifications

VERTICAL

*Channels : 4Ch + Ext

*Bandwidth : DC-100MHz(-3dB)

*Calculated Rise Time : 3.5ns

*Bandwidth Limit : 20MHz

*Vertical Resolution : 8 bits : 10mV – 10V/div

*Record Length : Max. 10Mpts

*Real Time Sampling Rate : 1GSa/s max

*Waveform Update Rate : 50,000wfms/s

TRIGGER

*Source : CH1, CH2, CH3, CH4, Line, Ext

*Trigger Mode : Auto (Supports Roll Mode for 100 ms/div and slower), Normal, Single Sequence

EXT TRIGGER

*Range : ±15V

*Sensitivity : DC – 100MHz Approx. 100mV; 100MHz – 200MHz Approx. 150mV

HORIZONTAL

*Time base Range : 1ns/div – 100s/div (1-2-5 increments); ROLL : 100ms/div – 100s/div

*Pre-Trigger : 10 div maximum

DISPLAY : 7” 800 x 480 TFT WVGA color display

INTERFACE : USB Port, Ethernet Port (LAN), Go/NoGo BNC

POWER SOURCE : AC 100V – 240V, 50Hz – 60Hz, auto selection, 30 Watts

DIMENSIONS & WEIGHT : 380(W) X 208(H) X 127.3(D)mm, Approx. 2.8 kg

ACCESSORIES : User manual CD x 1, Power cord x 1, GTP-100B-4 100MHz Passive Probe. Suitable for GDS-1104B, GDS-1102B

===========================================================
