GW Instek GDS-2202E 200MHz, 2-Channel Digital Storage Oscilloscope

GW Instek GDS-2202E 200MHz, 2-Channel Digital Storage Oscilloscope

============================================================

Features

·             200MHz Bandwidth Selection; 2 Channels

·             1GSa/s Real-Time Sampling Rate for Each Channel

·             Per Channel 10M Memory depth and VPO Waveform Display Technology

·             FFT with Maximum 1M points to Provide Higher Frequency Domain Resolution Measurement

·             29,000 Sections of Segmented Memory and Waveform Search Functions

============================================================

Specifications

VERTICAL SENSITIVITY

*Channels : 2Ch + Ext

*Bandwidth : DC-200MHz(-3dB)

*Calculated Rise Time : 1.75ns

*Bandwidth Limit : 20M/100MHz

*Vertical Resolution : 8 bits : 10mV – 10V/div

*Record Length : 10M/ch

*Real Time Sampling Rate : 1 Gsa/s

*Waveform Update Rate : 120,000wfms/s

TRIGGER

*Source : CH1, CH2, Line, Ext

*Trigger Mode : Auto (Supports Roll Mode for 100 ms/div and slower), Normal, Single Sequence

EXT TRIGGER

*Range : ±15V

*Sensitivity : DC – 100MHz Approx. 100mV; 100MHz – 200MHz Approx. 150mV

HORIZONTAL

*Time base Range : 1ns/div – 100s/div (1-2-5 increments); ROLL : 100ms/div – 100s/div

*Pre-Trigger : 10 div maximum

DISPLAY : 8” 800 x 480 TFT WVGA color display

INTERFACE : USB Port, Ethernet Port (LAN), Go/NoGo BNC

POWER SOURCE : AC 100V – 240V, 50Hz – 60Hz, auto selection

DIMENSIONS & WEIGHT : 384(W) X 208(H) X 127.3(D)mm, Approx. 2.8 kg

ACCESSORIES : User manual CD x 1, Power cord x 1, GTP-200B-4 200MHz (10:1/1:1) Switchable passive probe for GDS-2202E/2204E (one per channel)

===========================================================
