GW Instek GDS-3352 350MHz, 2 Channels Digital Storage Oscilloscope

GW Instek GDS-3352 350MHz, 2 Channels Digital Storage Oscilloscope

============================================================

Features

·         350MHz with 2 Channels

·         5GSa/s RT or 100GSa/s ET Sampling Rate

·         Independent Memory for Each Channel

·         VPO Technology

·         Large 8-inch 800x600 Display

·         Split Screen Function

·         3 Built-in Impedances (50Ω/75Ω/1MΩ)

============================================================

Specifications

Channels : 2ch + Ext

Bandwidth : DC ~ 350MHz (–3dB)

Calculated RiseTime : 1ns

Bandwidth Limit : 20M/100M/200MHz

Display : TFT LCD Type 8" TFT LCD SVGA color display

Interface : RS232C, USB Port, Ethernet Port (LAN), SVGA Video Port

Operating Temperature : 0°C to 50°C, Relative Humidity 80% at 40°C or below ; 45% at 41°C to 50°C

Power Source : AC 100V to  240V, 48Hz to 63Hz, auto selection

Dimensions : 400(W) X 200(H) X 130(D)mm

Weight : Approx. 4 kg

Accessories : User manual x 1, Power cord x 1, GTP-351R : 350MHz 10:1 passive probe for GDS-3352 (one per channel)

===========================================================
