GW Instek SPD-3603 375W Dual Range D.C. Power Supply

GW Instek SPD-3603 375W Dual Range D.C. Power Supply

============================================================

Features

·         Three independent, isolated output

·         CH3 adjustable output : 0.1 - 5V/3A

·         High efficiency power conversion (up to 25% more than traditional power supply)

·         Remote output on/off control

·         OVP to protect the DUT

·         OTP to protect SPD-3606 to decreas the repair rate

·         Compact size, light weight

·         Low Fan acoustic noise with fan speed control circuit

============================================================

Specifications

OUTPUT RATING

-CH1/CH2 Independent : 0 – 30V/0 – 6A; 0 – 60V/0 – 3A

-CH1/CH2 Series : 0 – 60V/0 – 6A; 0 – 120V/0 – 3A

-CH1/CH2 Parallel : 0 – 30V/0 – 12A; 0 – 60V/0 – 6A

-CH3 : 0.1 – 5V/3A

VOLTAGE REGULATION

-Line : ≤0.01% + 3mV

-Load : ≤0.01% + 5mV (rating current ≤6A); ≤0.01% + 8mV (rating current >12A)

-Ripple & Noise : ≤5mVrms (5Hz – 1MHz); ≤50mVpp (20Hz – 20MHz)

-Recovery Time : ≤100µS (50% Load change, Minimum load 0.5A)

CURRENT REGULATION

-Line : ≤0.2% + 3mA

-Load : ≤0.2% + 3mA

-Ripple & Noise : ≤3mArms

TRACKING OPERATION

-Tracking Error : ≤0.5% + 10mV of master

-Series Regulation : ≤300mV

-Ripple & Noise : ≤10Vrms (5Hz – 1MHz); ≤100mVpp (20Hz – 20MHz)

OUTPUT ON/OFF RESPonSE TIME

-Voltage Up (10% - 90%) : ≤100ms (≤95% rating load)

-Voltage Down (90% - 10%) : ≤100ms (≥10% rating load)

OVP

-Accuracy : ±(0.5% of reading + 0.5V)

METER

-Type : 3 ½ digits 0.5” LED display

-Accuracy : ±(0.5% of reading + 2 digits)

-Resolution : 100mV/10mA

INSULATION

-Chassis and Terminal : 100MΩ or above (DC 1000V)

-Chassis and AC Cord : 100MΩ or above (DC 1000V)

REMOTE ConTROL : Output On/Off

FAN NOISE : ≤50dB

POWER SOURCE : AC 115V/230V ±15%, 50/60Hz

DIMENSIONS & WEIGHT : 255(W) x 145(H) x 265(D) mm; Approx. 6kg

ACCESSORIES : User manual x 1, Power cord x 1, Test Lead GTL-104 x 2; GTL-105 x 1

===========================================================
