GW Instek APS-7050 500VA Programmable AC Power Source

GW Instek APS-7050 500VA Programmable AC Power Source

============================================================

Features

·         4.3-inch TFT-LCD

·         Output capacity : APS-7050(500VA, 310Vrms, 4.2Arms); APS-7100 (1000VA, 310Vrms, 8.4Arms)

·         Low Ripple & Noise

·         Measurement and test functions include VOLTCURR、PWR、SVA、IPK、IPKH、FREQ、PF、CF

·         Support a small AC current measurement 2mA ~ 35A, Min. resolution 0.01mA(APS- 7050& APS-7100)

·         Reverse Current Alarm Function

·         10 sets of Sequence function to Edit Output Waveforms/ 10 sets of simulate mode to Rapidly Simulate Transient Power Supply/ 10 sets of Program mode to Define Measurement Sequence/ 10 sets of Panel Memory Function

·         Automatic Execution of Sequence、Simulate、Program mode and Output Function when the Power is on

·         Standard Interfaces: LAN, USB Host

============================================================

Specifications

AC OUTPUT

-Power Rating : 500VA

-Output Voltage : 0 – 155Vrms/0 – 310Vrms

-Output Frequency : 45.00 – 500.0Hz

-Maximum Current (r.m.s) :

0 – 155Vrms : 4.2A

0 – 310Vrms : 2.1A

-Maximum Current (r.m.s) :

0 – 155Vrms : 16.8A

0 – 310Vrms : 8.4A

-Total Harmonic Distortion (THD) : ≤ 0.5% at 45 -50Hz (Resistive Load)

-Crest Factor : ≤ 4

-Line Regulation : 0.1% (% of full scale)

-Load Regulation : 0.3% (% of full scale)

-Response Time : <100µs

-Reverse Current : 30% of Maximum Output RMS Current (Continue) 100% of Maximum Output RMS Current (Within 3 minutes)

AC INPUT

-Phase : Single Phase

-Input Voltage : 115/230Vac ±15%

-Input Frequency : 50/60Hz

-Max. Current : 16A/8A

-Power Factor : 0.7 Typ.

-Power Consumption : 1.8kVA or less

INTERFACE : USB Host, LAN

DIMENSIONS & WEIGHT : 430(W) x 88 (H) x 400(D) mm; Approx. 24kg

ACCESSORIES : CD ROM(User Manual, Programming Manual for APS-7000) x 1, Power Cord(Region Dependent), GTL-123 Test Lead

===========================================================
