GW Instek APS-7100E 1000VA AC Power Source

GW Instek APS-7100E 1000VA AC Power Source

============================================================

Features

·         4.3 inch TFT-LCD Display

·         Output Capacity: APS-7050E(500VA, 310Vrms, 4.2/ 2.1Arms), APS-7100E(1000VA, 310Vrms, 8.4/ 4.2Arms)

·         only 88mm(2U) case height

·         Measurement function comprises Voltage, Current, Power, Current(peak), Frequency, Power Factor

·         10 sets of the Test mode simulate power transient output

·         10 sets of Preset allow users to store ten settings

============================================================

Specifications

POWER RATING : 1000VA

OUTPUT VOLTAGE : 0 – 155VRMS/0 – 310VRMS

OUTPUT FREQUENCY : 45 – 500Hz

MAXIMUM CURRENT  (R.M.S)

-0 – 155VRMS : 8.4A

-0 – 310VRMS : 4.2A

MAXIMUM CURRENT (PEAK)

-0 – 155VRMS : 33.6A

-0 – 310VRMS : 16.8A

TOTAL HARMonIC DISTORATION (THD) : ≤ 0.5% at 45 – 500Hz (Resistive Load)

CREST FACTOR : ≤ 4

LINE REGULATION : 0.1% (% of full scale)

LOAD REGULATION : 0.3% (% of full scale)

RESPonSE TIME : < 100µS

REVERSE CURRENT : 30% of Maximum Output RMS Current (Continue) 100% of Maximum; Output RMS Current (Within 3 minutes)

GENERAL

-Number of Preset : 10 (0 – 9 Numeric keys)

-Protection : OCP, OPP, OTP and Alarm

AC INPUT

-Input Power Source : 1ȹ AC 115/230Vac ±15%

DIMENSIONS & WEIGHT : 430(W) x 88(H) x 560(D) mm; Approx. 38kg

ACCESSORIES : CD ROM (User Manual x 1), Power Cord (Region Dependent), Mains Terminal Cover Set, GTL-123 Test Lead

===========================================================
