GW Instek GDM-8255A 199999 Counts Dual Display Digital Multimeter

GW Instek GDM-8255A 199999 Counts Dual Display Digital Multimeter

============================================================

Features

·         GDM-8255A 199,999 Counts Display

·         VFD Two Colors Display

·         0.012% DCV Accuracy

·         True RMS (AC, AC+DC)

·         9 Major Measuring Functions and 10 Advanced Measurement Functions

·         2W/4W Resistance Measurement

·         High Voltage 1000V and 10A Current Range

·         Standard Interface : RS-232C, USB Device, Digital I/O

·         Free PC Software (DMM-VIEWER), LabVIEW Driver

·         Optional: 16+2 Channels Scanner Card

============================================================

Specifications

FULL SCALE : 19999 Counts

SAMPLE RATE

-Slow : 5 1/2 digits, 10 readings/second

-Medium : 4 1/2 digits, 30 readings/second

-Fast : 3 1/2 digits, 60 readings/second

DC VOLTAGE

-Range : 100mV, 1V, 10V, 100V, 1000V 5 ranges

-Accuracy : ±(0.012% rdg + 5 digits)

-Input Impedance : 10MΩ

AC VOLTAGE True RMS

-Range : 100mV, 1V, 10V, 100V, 750V 5 ranges

-Accuracy : 20Hz - 45Hz : ±(1% rdg + 100 digits); 45Hz - 10kHz : ±(0.2% rdg + 100 digits); 10kHz - 30kHz : ±(1% rdg + 100 digits); 30kHz - 100kHz : ±(3% rdg + 200 digits)

-Input Impedance : 1.1MΩ in parallel with approx. 100pF

DC CURRENT

-Range : 10mA, 100mA, 1A, 10A 4 ranges

-Accuracy : 10mA, 100mA : ±(0.05% rdg + 15 digits); 1A, 10A range : ±(0.2% rdg + 5 digits)

AC CURRENT True RMS

-Range : 10mA, 100mA, 1A, 10A 4 ranges

-Acuracy : 10mA, 100mA range : 20Hz - 50Hz : ±(1.5% rdg + 100 digits); 50Hz - 10kHz : ±(0.5% rdg + 100 digits); 10kHz - 20kHz : ±(2% rdg + 200 digits). 1A, 10A range : 50Hz - 10kHz : ±(1% rdg + 100 digits)

RESISTANCE

-Range : 100Ω, 1kΩ, 10kΩ, 100kΩ, 1MΩ, 10MΩ, 100MΩ 7 ranges

-2W Accuracy : 100Ω range : ±(0.1% rdg + 8digits)(*);  100Ω range : ±(0.05% rdg + 8 digits)(*); 1kΩ range : ±(0.08% rdg + 5 digits)(*); 10kΩ - 1MΩ 3 ranges : ±(0.06% rdg + 5digits); 1kΩ - 1MΩ 4 ranges : ±(0.05% rdg + 5 digits); 10MΩ range : ±(0.3% rdg + 5 digits); 10MΩ range : ±(0.3% rdg + 5 digits); 100MΩ range : ±(3% rdg + 8 digits)

-4W Accuracy : 100Ω range : ±(0.05% rdg + 8 digits)(*); 1kΩ - 1MΩ 4 ranges : ±(0.05% rdg + 5 digits); 10MΩ range : ±(0.3% rdg + 5 digits); 100MΩ range : ±(3% rdg + 8 digits)

FREQUENCY

-10Hz - 800kHz : 0.1V; Accuracy : ±(0.05% rdg + 15 digits)

-100kHz - 600kHz : 1V; Accuracy : ±(0.05% rdg + 3 digits)

-600kHz - 800kHz : 2.5V; Accuracy : ±(0.05% rdg + 3 digits)

DIODE TEST : Open Circuit Voltage 2.0V, Test Current 0.5mA; Accuracy : ±(0.025% rdg + 5 digits)

ConTINUITY BEEPER : 1 - 1000Ω Define by user; Accuracy : ±(0.08% rdg + 5 digits)

TEMPERATURE : 0°C - 300°C : J, K, T Type

OTHER FUNCTION : Auto range / Manual, Math : MX + B/ % / 1/X Max, Min, dBm, dB, REL, Hold, Compare, Store, Recall

DISPLAY : VFD, Two Colors Display

INTERFACE : Digital I/O, USB, RS-232C

POWER SOURCE : AC 100V - 240V 10%, 50/60Hz

DIMENSIONS & WEIGHT : 265(W) x 107(H) x 350(D) mm, Approx. 2.6 kg

ACCESSORIES : Quick start user manual x 1, Power cord x 1, Test lead GTL-207A x 1, USB Cable GTL-247 x 1, CD x 1 (including complete user manual, upgrade program and PC software DMM Viewer), Calibration key GDM-01 x1

===========================================================
