GW Instek GDM-8351 5 ½ Digit Dual Measurement Multimeter

GW Instek GDM-8351 5 ½ Digit Dual Measurement Multimeter

============================================================

Features

·         120,000 counts, VFD display

·         Dual measurement/Dual display

·         The basic precision of DC voltage: 0.012%

·         Selectable measurement speeds, the maximum: 320 Readings/s

·         True RMS (AC，AC+DC) measurements

·         Auto/manual selection

·         12 different measurement functions: AC/DC voltage, AC/DC current, AC+DC voltage/current, 2W/4W resistance, continuity beeper, diode test, capacitance, frequency, temperature

·         Many auxiliary functions: Max./Min., REL/REL#, Compare, Hold, dB, dBm, Math (MX+B, %, 1/X)

·         Digital I/O provides dual mode (standard Compare and User definition modes)

·         Standard RS-232C and USB device interface (support USBCDC and USBTMC modes)

============================================================

Specifications

DC VOLTAGE

-Range : 100mV – 1000V

-Resolution : 1µV – 10mV

RESISTANCE

-Range : 100Ω - 100MΩ

-Resolution : 1mΩ - 1kΩ

DC CURRENT

-Range : 10mA – 10A

-Resolution : 100nA – 100µA

CONTINUITY

-Range : 100Ω

-Resolution : 10mΩ

DIODE TEST

-Range : 6V

-Resolution : 100µV

CAPACITANCE

-Range : 10nF - 100µF

-Resolution : 0.01nF – 0.1µF

TRUE RMS AC (or AC+DC – AC Coupled) VOLTAGE

-Range : 100mV – 750V

-Resolution : 1µV – 10mV

TRUE RMS AC (or AC+DC – AC Coupled) CURRENT

-Range : 10mA – 10A

-Resolution : 10nA – 100µA

FREQUENCY :

-Voltage : 10Hz – 1MHz

-Current : 20Hz – 10kHz

THERMOCOUPLE TEMPERATURE : -200°C - 300°C (J/T/K)

DISPLAY : VFD, Two Colors Display

INTERFACE : RS-232C, USB device (USBCDC & USBTMC)

POWER SOURCE : AC 100V/120V/220V/240V ±10%, 50-60Hz, Max. 15VA

DIMENSIONS & WEIGHT : 265(W) x 107(H) x 302(D)mm, Approx. 2.9kg

ACCESSORIES : Safety Instruction Sheet x 1, Power cord x 1, Test lead GTL-207A x 1, CD x 1 (including complete user manual, driver and software)

===========================================================
