GW Instek GPT-9903A 500VA AC/DC Withstanding Voltage/Insulation Resistance Tester

GW Instek GPT-9903A 500VA AC/DC Withstanding Voltage/Insulation Resistance Tester

============================================================

Features

·         500VA AC Test Capacity

·         Short Current > 200mA

·         240x64 Ice Blue Dot matrix LCD

·         Sweep Function for DUT characteristic analysis

·         Insulation resistance measurement up to 50GΩ(GPT-9903A/9904)

·         Manual/Auto Mode

·         Function Key for quick selection

·         High intensity flash for caution & Status indication

·         Safety INTERLOCK function

============================================================

Specifications

AC WITHSTANDING

-Output-Voltage Range : 0.050kV -  5.000kV AC

-Output-Voltage Resolution : 2V/step

-Output-Voltage Accuracy : ±(1% of setting + 5V) [no load]

-Maximum Rated Load : 500VA (5kV/100mA)

-Maximum Rated Current : 100mA (0.5kV <V ≤5kV); 10mA (0.1kV ≤V ≤0.5kV)

DC WITHSTANDING

-Output-Voltage Range : 0.050kV - 6.000kV DC

-Output-Voltage Resolution : 2V/step

-Output-Voltage Accuracy : ±(1% of setting +5V) [no load]

-Maximum Rated Load : 100W (5kV/20mA)

-Maximum Rated Current : 20mA (0.5kV <V ≤6kV); 2mA (0.05kV ≤V ≤0.5kV)

INSULATION RESISTANCE

-Output-Voltage : 50V - 1000V DC

-Output-Voltage Resolution : 50V/step

-Output-Voltage Accuracy : ±(1% of setting +5V) [no load]

-Resistance Measurement Range : 0.001GΩ - 50.00GΩ

MEMORY

-Single Step Memory : MANU : 100 blocks

-Automatic Testing Memory : AUTO : 100 blocks, menu per auto : 16

INTERFACE : Rear Output, RS232, USB (Device), Remote Terminal (Front), SIGNAL I/O

DISPLAY : 240 x 64 dot matrix LED back light LCD

POWER SOURCE : AC100V/120V/220V/230V ±10%, 50/60Hz, 1000VA max.

DIMENSIONS & WEIGHT : 330(W) x 148(H) x 482(D) mm, approx. 27kg(Max)

ACCESSORIES : Quick Start Guide x1, CD x1(completed user manual), Power cord x1, Interlock key x1, Remote terminal Cable GHT-119 x1, Test lead GHT-114 x1

===========================================================
