GW Instek GPT-9601 100VA AC Withstanding Voltage Tester

GW Instek GPT-9601 100VA AC Withstanding Voltage Tester

============================================================

Features

·         100VA AC Test Capacity

·         240x48 Ice Blue Dot matrix LCD

·         Auto W-I or I-W Mode

·         ARC Detection

·         RMS Current Measurement

·         Zero Crossing Turn-on Operation

·         Safety INTERLOCK function

·         PWM amplifier to enhance the power efficiency and reliable testing

·         Automatically Switching Input Source for Universal Input Voltage

·         Interface : Remote terminal and Signal I/O

============================================================

Specifications

AC WITHSTANDING

-Output-Voltage Range : 0.10kV -  5.00kV AC

-Output-Voltage Resolution : 10V

-Output-Voltage Accuracy : ±(1.5% of setting +2 counts) with no load

-Maximum Rated Load : 100VA (5kV/20mA)

-Maximum Rated Current : 20mA (0.5kV <V ≤5kV); 5mA (0.1kV ≤V ≤0.5kV)

TEST MODE

-SINGLE : ACW, DCW, IR

-AUTO : AC-IR, IR-AC, DC-IR, IR-DC

INTERFACE

-Remote Terminal  (Front) : Standard

-SIGNAL I/O : Standard

DISPLAY : 240 x 48 Ice Blue dot matrix LCD

POWER SOURCE : AC100V - 120V/220V - 240V ±10%, 50/60Hz, 400VA max.

DIMENSIONS & WEIGHT : 330(W) x 148(H) x 358(D) mm, approx. 9kg(Max)

ACCESSORIES : Quick Start Guide x1, CD x1(completed user manual), Power cord x1, Interlock key x1, Remote terminal Cable GHT-119 x1, Test lead GHT-114 x1

===========================================================
