GW Instek PCS-1000I Isolated Output High Precision Current Shunt Meter

GW Instek PCS-1000I Isolated Output High Precision Current Shunt Meter

============================================================

Features

·         6 1/2 digit voltage and current measurement resolution

·         Simultaneous current and voltage measurement

·         Five current measurement levels (AC&DC): 30mA/ 300mA/ 3A/ 30A/ 300A

·         AC voltage measurement levels: 200mV/ 2V/ 20V/ 200V/ 600V

·         DC voltage measurement levels: 200mV/ 2V/ 20V/ 200V/ 1000V

·         Standard: USB& GPIB

·         CE verification

============================================================

Specifications

DC VOLTAGE

-Range : 200mV – 1000V

-Accuracy : ±(% of reading + % of range)

-Resistance : 10MΩ for all DC voltage ranges

DC CURRENT

-Range : 30mA – 300A

-Burden Voltage : <0.4V

ISOLATED DC CURRENT MonITOR ACCURACY

-Range : 30mA – 300A

TRUE RMS AC VOLTAGE

-Range : 200mV – 600V

-Frequency : 45Hz – 20kHz

TRUE RMS AC CURRENT

-Range : 30mA – 300A

-Frequency : 45Hz – 400Hz

ISOLATED AC CURRENT MonITOR ACCURACY

-Range : 30mA – 300A

-Frequency : 45Hz – 400Hz

POWER SOURCE : 100V/120V/220V/240V ±10%; 50/60Hz; Max. 35VA

DIMENSIONS & WEIGHT : 210(W) x 80(H) x 390(D)mm; Approx. 5 kg

ACCESSORIES : Quick Operation Guide x1, User Manual (CD) x1, AC Power Cord x1 (by region), Alligator Clip Test Lead GTL-105A x1, Banana Plug Test Lead GTL-207A x1, USB Cable GTL-240 x1, Basic Accessory Kit PCS-001

===========================================================
