GW Instek PLR 60-6 (0-60V/00-6A/360W) Low Noise DC Power Supply

GW Instek PLR 60-6 (0-60V/00-6A/360W) Low Noise DC Power Supply

============================================================

Features

·         Output Voltage Rating : 20V/36V/60V

·         Output Power : 360W/720W

·         Low Ripple and Noise (0.5mVrms/ 10mArms)

·         Fast transition recovery time (100us)

·         Maximum 2 units in series connections or 3 units in parallel connections

·         Select the setting digits for voltage and current (coarse/ fine volume control)

·         Panel Lock Function

·         3 set of preset function

·         Output off timer function (Range:1 min to 1000 hours & 59mins)

·         CC priority function (prevent overshoot & inrush current)

·         Sequence function of PC editing (Max. : 1000 steps/ Min. step period : 50ms)

·         Protection: OVP, UVP, OCP, remote sensing (Terminal open)

·         External Analog Control Function

·         PC Remote Interface (Standard : RS-232)

·         CE Compliance

============================================================

Specifications

OUTPUT RATING

*Voltage : 0V – 60V

*Current : 0 – 6A

*Power : 360W

REGULATION (CV)

*Load : 5mA

*Line : 4mA

REGULATION (CC)

*Load : 5mA

*Line : 1mA

RIPPLE & NOISE (Noise Bandwidth=20MHz; Ripple Bandwidth=1MHz)

*CV p-p : 30mVp-p

*CV rms : 0.5mVrms

*CC rms : 5mArms

SETTING RESOLUTION

*Voltage : 10mV

*Current : 10mA

MEASUREMENT RESOLUTION

*Voltage : 10mV

*Current : 10mA

SERIES AND PARALLEL CAPABILITY

*Parallel Operation : Up to 3 units

*Series Operation : Up to 2 units

INTERFACE : RS-232/Local bus

POWER ConSUMPTION : 510VA

POWER FACTOR : 0.99

POWER SOURCE : Single-phase 100VAC to 240VAC, 50Hz to 60Hz

DIMENSIONS & WEIGHT : 140 (W) x 139.5 (H) x 415.5 (D) mm, Approx. 5.2kg

ACCESSORIES : User Manual(CD) x 1, Power Cable x 1, Rear Output Terminal Cover x 1, Bolt set x 1(Hexagon head bolt P-3 x 2, Flat washer x 2, Hexagon nut x 2), Output grounding cable x 1, M4 Small Screw Washer x 1, M3 Small Screw Washer x 1, M3 Large Screw Washer x 2

===========================================================
