GW Instek GSP-730 150kHz – 3GHz Spectrum Analyzer

GW Instek GSP-730 150kHz – 3GHz Spectrum Analyzer

============================================================

Features

·         Frequency Range : 150kHz - 3GHz

·         Autoset Function

·         Noise Floor: ≤-100dBm

·         RBW Range : 30kHz, 100kHz, 300kHz, 1MHz

·         ACPR/CHPW/OCBW Measurement

·         3 Traces in Different Colors

·         Split Window Function

·         Limit Line Function

·         Remote Control Software

·         Presentation Material for Training Courses

·         Support Interface : USB Device/Host, RS-232C

============================================================

Specifications

FREQUENCY

*Range : 150kHz – 3GHz

*Resolution : 0.1MHz

*Bandwidth Range : 30kHz, 100kHz, 300kHz, 1MHz

AMPLITUDE

*Input Range : +20 – 40dBm

*Accuracy : Within ±2dB (1GHz); SPAN : 5MHz

*Noise Level : 5 -100dBm (typical, center frequency: 1GHz RBW: 30kHz)

SWEEP

*Range : 300ms – 8.4s, auto (not adjustable)

*Accuracy : within 12% (frequency span : full span)

DISPLAY : 640 x 480 RGB color LCD

INTERFACE : RS232C, USB Connector, Sub-D female-D 9 pins

POWER SOURCE : AC 100 – 240V, 50/60Hz

DIMENSIONS & WEIGHT : 296(L) x 153(W) x 105(H)mm; Approx.2.2 Kg

ACCESSORIES : Quick Start manual x 1, User Manual CD x 1, Power Cord x 1

===========================================================

UNTUK MENGHINDARI PESANAN BARANG ANDA DITOLAK OLEH KAMI, SILAHKAN BERTANYA STOCK BARANG TERLEBIH DAHULU. TERIMA KASIH

Untuk informasi dan pemesanan, silahkan menghubungi :

Telp. & WA : 62.813.3117.0440

Mail : asiaindustri@gmail.com

============================================================
