GW Instek GSP-9300B 3GHz Spectrum Analyzer

GW Instek GSP-9300B 3GHz Spectrum Analyzer

============================================================

Features

·         Frequency Range: 9kHz ~ 3 GHz

·         0.025ppm Frequency Stability and 1ppm aging Rate

·         Built-in Preamplifier, 50dB Attenuator, and Sequence Function

·         RBW: 1Hz ~ 1MHz

·         Sensitivity: -149dBm/Hz (@PreAmp on)

·         Built-in AM/FM Demodulation & Analysis

·         Built-in P1dB point, Harmonic, Channel Power, N-dB bandwidth, OCBW, ACPR, SEM, TOI, CNR, CTB, CSO, Noise Marker, Frequency Counter, Time Domain Power, Gated Sweep

·         Built-in Spectrogram, Topographic and Dual-View Display Modes

·         Remote Control Interface: LAN, USB, RS-232

============================================================

Specifications

FREQUENCY

*Range : 9kHz – 3GHz

FREQUENCY REFERENCE

*Accuracy : ±(period since last adjustment x aging rate) + stability over temperature + supply voltage stability

FREQUENCY READOUT ACCURACY

*Start, Stop, Center, Marker : ±(marker frequency indication x frequency reference accuracy + 10% x RBW + frequency resolution)

MARKER FREQUENCY COUNTER

*Resolution : 1 Hz, 10 Hz, 100 Hz, 1 kHz

VIDEO BANDWIDTH (VBW) FILTER

*Filter Bandwidth : 1Hz – 1MHz in 1-3-10 sequence

AMPLITUDE

*Measurement Range : 100kHz – 1MHz; 1MHz – 10MHz; 10MHz – 3GHz

ATTENUATOR

*Input Attenuator Range : 0 – 50 dB, in 1 dB steps

SWEEP TIME

*Range : 204µS – 1000s; 50µs – 1000s

RF PREAMPLIFIER

*Frequency Range : 1MHz – 3GHz

RF INPUT : N-type female; 50Ω

POWER FOR OPTION : SMB male

USB HOST : A plug

EARPHONE OUTPUT : 3.5mm stereo jack, wired for mono operation

VIDEO OUTPUT : DVI-I (integrated analog and digital), Single link. Compatible with VGA or HDMI standard through adapter

POWER SOURCE : AC 100V - 240V, 50/60 Hz, Auto range selection, < 65W

DIMENSIONS & WEIGHT : 350(W) x 210(H) x 100(D) mm, Approx. 4.5kg

ACCESSORIES : Power Cord, Certificate of Calibration, CD-ROM (with Quick Start Guide, User Manual, Programming Manual, SpectrumShot Software, SpectrumShot Guide & IVI Driver)

===========================================================
