C30/C30M Spectrometer PG Instruments

Spectrometer C30/C30M PG Instruments

Description

The C30 Portable Spectrometer is a compact portable instrument based on advanced CCD detection technology. Whilst being highly compact the instrument boasts all of the features of a conventional bench-top Spectrophotometer including Spectrum Scanning, Photometric, Quantitative and Kinetic Methods.

Specifications

Light Source

Convergent tungsten lamp with 7000 hr lifespan.

Measurement Workspaces

Spectrum

Quantitative

Kinetics

Photometric

Optical System

Polychromatic with concave holographic grating

Detector

CCD Sony ILX511 2048 Pixels

Sampling Accessories

Fibre Dip Probe with 10 mm and 20 mm pathlength tips ( optical accessory )

Rectangular Cuvette Holder

Cylindrical Test Tube Holder

Power supply

Built-in re-chargeable battery with 5 hr usage

Printer

Micro printer ( optional )

Operating system

Windows Embedded CE 6.0 with 2 GB Flash Memory

Input/display

320 x 240 True Colour TFT Touch Screen

Specifications

Wavelength range

380 nm – 800 nm

Wavelength resolution

0.4 nm

Spectral bandwidth

4 ±0.8 nm

Wavelength accuracy

±1.0 nm

Wavelength repeatability

<0.1 nm

baseline flatness

±0.005 Abs

Noise

<0.5 %

Drift

<1.0 %

Stray light

<0.5 %

Photometric accuracy

±1.0 %

Photometric repeatabilit

<0.3 %

Dimension

280 x 170 x 110mm

Environmental temperature

Operating environment 5 - 30 °C

Storage environment -20 - 55 °C
