Barnstead Smart2Pure Water Purification System

Barnstead Smart2Pure Water Purification Systems Thermo Scientific

Model

Smart2Pure Standard

Smart2Pure UV

Smart2Pure UF

Smart2Pure UV/UF

Type 1 Water

Applications examples

A A, IC, standard buffer

HPLC, GC-MS and ICP-MS, TOC Analysis, Trace Analysis

Microbiology, monoclonal antibodies, Cell Culture

Molecular biology, PCR, DNA sequencing, electrophoresis, cell culture media

Resistivity at 25°C, MΩ.cm

18,2

18,2

18,2

18,2

Conductivity, µS/cm

0,055

0,055

0,055

0,055

TOC value , ppb

05-Okt

1/5

5/10

1/5

Bacterial content in CFU/ml

<0.01

<0.01

<0.01

<0.01

Particles, µm/mL

<1

<1

<1

<1

Endotoxin, EU/ml

n/a

n/a

<0.001

<0.001

Flow Rate, L /min

1

1

0,6

0,6

Type 2 Water

Applications

Rinsing lab glassware, supplying autoclaves and ultrapure water systems, preparing and diluting buffers, reagents, and tissue culture media.

Pure water production at 15°C, L/h

3, 6, or 12

3, 6, or 12

3, 6, or 12

3, 6, or 12

Resistivity at 25°C, MΩ.cm

15-10 10-15

15/10

5/10

15/10

Conductivity, µS/cm

0.067 - 0.1

0.067 - 0.1

0.067 - 0.1

0.067 - 0.1

Ideal for your molecular biology, microbiology and analytical chemistry applications :

Type 1 Applications

Type 2 Applications

Cell and tissue culture

Rinsing lab glassware

PCR, DNA sequencing

Supplying general lab equipment

Electrophoresis, TOC Measurements, IC

Preparing and diluting buffers, reagents, and media

HPLC, GC-MS, ICP-MS, AA

Specifications

Model

Smart2Pure 3,6

Smart2Pure 12

Storage Reservoirs

30 L

60 L

Dimensions H x W x D

545 x 305 x 390 mm

545 x 305 x 300 mm

603 x 380 mm

914 x 380 mm

( 22 x 12 x 15 ) in

( 22 x 12 x 12 ) in

( 24 x 15 ) in

( 36 x 15 ) in

Product Weight kg (lbs) w/o water

21 ( 46 )

20 ( 44 )

8 ( 18 )

15 ( 33 )

Ship Dimensions H x W x D

706 x 455 x 430 mm

706 x 455 x 430 mm

706 x 455 x 430 mm

940 x 410 x 495 mm

( 28 x 18 x 17 ) in

( 28 x18 x 17 ) mm

( 28 x 18 x 17 ) in

( 37 x 16 x 19 ) in

Shipping Weight kg ( lbs.)

24-27 ( 52-60 )

22-25 ( 48-55 )

10 ( 22 )

17 ( 37 )

Required feed water quality

Source

Tap water

TDS

>500 ppm

Turbidity

> 1 N.T.U

pH Range

4 – 11

Temperature,°C

Feb-35

Pressure, psi ( bar )

1.4 - 87 ( 1 - 6 )

Order Informations

System Options

Permeate flow at

Smart2Pure

Smart2Pure UV

Smart2Pure UF

Smart2Pure UV/UF

15°C

Standard

Smart2Pure System

3 L /hr

50129869

50129872

50129870

50129688

Systems include RO/pretreatment cartridge, an ultrapure polisher cartridge,  sterile 0.2 µM filter, and UV lamp and/or UF filter where applicable. 3 and 6 L /hr version also include an internal 6L tank with vent filter.

6 L /hr

50129873

50129885

50129874

50129887
