Specifications

KERN

MLS 50-3HA160N

Readout [ d ]

0,001 g / 0,01 %

Weighing range [ Max ]

50 g

Reproducibility, weight of sample 2 g

0,50 %

Reproducibility, weight of sample 10 g

0,02 %

Display after drying ( Display can be switched over at any time )

Moisture [ % ] = Weight loss

0 - 100 %

( WL ) from SW ( startweight )

Dry mass [ % ] = Residual weight ( RW ) from SW

100 - 0 %

ATRO [ % ]  [( SG-RG )  : RG ] · 100 %

0 - 999 %

Restgewicht [g]

Absolute value in [ g ]

Temperature range

50° - 160 °C in steps up to 1 °C

Drying modes

• Standard drying

• Drying in levels

• Gentle drying

• Pre-heat level, can be switched on

Switch off criteria

• When the set time has expired ( 1 - 9 h 59 min )

• When the weight loss per unit of time falls below the target value

( both values freely adjustable mg/sec )

Recall of measurement

Interval adjustable from 1 sec - 5 min

( only in connection with KERN YKB-01N printer or PC )

Overall dimensions W x D x H

210 x 335 x 156 mm

Net weight

approx. 6,3 kg

Option DKD Calibr. Certificate

963-127
