HI-96771 Ultra High Range Chlorine Portable Photometer Hanna

Ultra High Range Chlorine HI96771 Portable Photometer Hanna Instruments

The HI96771 is available as a kit ( HI96771C ) which includes :

Portable Photometer

Sample cuvettes (2)

Caps

CAL Check™ standards with certificate

Cuvette cleaning cloth

Scissors

Rugged carrying case

Carrying case has thermoformed insert for meter and accessories

*Reagents ordered separately

CAL Check™ standards with certificate

The HI96771-11 CAL Check™standards are used for calibration and performance verification of photometers with the CAL Check function.

Supplied with Certificate of Analysis

Lot number

Expiration date

Standard value @ 25 °C

Reference meter NIST traceable

Provided storage containers

Light tight

Protects from accidental breakage

Absorbance Specifications

Light Source

Tungsten lamp

Light Detector

Silicon photocell with narrow band interference filter @ 525 nm

Additional Specifications

Range

Free Chlorine ( P1 ) : 0.00 to 5.00 mg/L ( ppm ); Ultra High Range Chlorine ( P2 ) : 0 to 500 mg/L ( ppm );

Resolution

Free Chlorine ( P1 ) : 0.01 mg/L from 0.00 to 3.50 mg/L; 0.10 mg/L above 3.50 mg/L; Ultra High Range Chlorine ( P2 ) : 1 mg/L from 0 to 200 mg/L; 10 mg/L above 200 mg/L

Accuracy @ 25 °C ( 77 °F )

Free Chlorine ( P1 ) : ±0.03 mg/L ±3 % of reading; Ultra High Range Chlorine ( P2 ) : ±3 mg/L ±3 % of reading

Method

Adaptation of the Standard Methods for the Examination of Water and Wastewater, 4500-Cl method

Auto-off

After ten minutes of non-use in measurement mode; after one hour of non-use in calibration mode; with last reading reminder

Environment

0 to 50 °C ( 32 to 122 °F ); RH max 95 % non-condensing

Weight

360 g (12.7 oz.)

Battery Type

9 V battery

Dimensions

193 x 104 x 69 mm ( 7.6 x 4.1 x 2.7” )

Ordering Information

HI96771 is supplied with sample cuvettes ( 2 ) with caps, 9V battery, instrument quality certificate and instruction manual.

Warranty

1 year
