HI-96700 Ammonia Meter Photometer Hanna Instruments

Ammonia Meter HI-96700 Photometer Hanna Instruments

The HI96700 is available as a kit ( HI96700C ) which includes

Portable Photometer

Sample cuvettes (2)

Caps

CAL Check™ standards with certificate

Cuvette cleaning cloth

Rugged carrying case

Carrying case has thermoformed insert for meter and accessories

*Reagents ordered separately

CAL Check™ standards with certificate

The HI96700-11 CAL Check™standards are used for calibration and performance verification of photometers with the CAL Check function.

Supplied with Certificate of Analysis

Lot number

Expiration date

Standard value @ 25 °C

Reference meter NIST traceable

Provided storage containers

Light tight

Protects from accidental breakage

Absorbance Specifications

Light Source

Tungsten lamp

Light Detector

Silicon photocell with narrow band interference filter @ 420 nm

Additional Specifications

Range

0.00 to 3.00 mg/L ( ppm ) ( as ammonia-nitrogen )

Resolution

0.01 mg/L

Accuracy @ 25°C ( 77°F )

±0.04 mg/L ±4% of reading

Method

Adaptation of the ASTM Manual of Water and Environmental Technology, D1426-93, Nessler method

Auto-off

After ten minutes of non-use in measurement mode; after one hour of non-use in calibration mode; with last reading reminder

Environment

0 to 50°C ( 32 to 122°F ); RH max 95% non-condensing

Weight

360g ( 12.7oz. )

Battery Type

9V battery

Dimensions

193 x 104 x 69 mm ( 7.6 x 4.1 x 2.7” )

Ordering Information

HI96700 is supplied with sample cuvettes (2) with caps, 9V battery, instrument quality certificate and instruction manual.
