Furnaces RHF Carbolite Gero

Furnaces RHF Carbolite Gero

Technical Specifications

Model

RHF 14/3

RHF 14/8

RHF 14/15

Max temp ( °C )

1400

1400

1400

Volume ( litres )

3

8

15

Heat-up time ( mins )

33

22

35

Dim Int H x W x D ( mm )

120 x 120 x 205

170 x 170 x 270

220 x 220 x 310

Dim Ext H x W x D ( mm ) H ( door open )

655 x 435 x 610 ( 905 )

705 x 505 x 675 ( 990 )

810 x 690 x 780 ( 1105 )

Configuration

Bench-top

Bench-top

Bench-top

Max power ( W )

4500

8000

10000

Holding power ( W )

1900

3200

2900

Thermocouple type

R

R

R

Weight ( kg )

42

64

125

Power supply required per phase

Single phase 200-240V 30A,380-415V 2 phase 15A

Single phase 200-240V 50A,380-415V 2 phase + N 25A

Single phase 200-240V 62A,380-415V 3 phase + N 22A,200-220V 3 phase delta 38A

Model

RHF 14/35

RHF 15/3

RHF 15/8

Max temp ( °C )

1400

1500

1500

Volume ( litres )

35

3

8

Heat-up time ( mins )

38

45

40

Dim Intl H x W x D ( mm )

250 x 300 x 465

120 x 120 x 205

170 x 170 x 270

Dim Ext H x W x D ( mm ) H ( door open )

885 x 780 x 945 ( 1245 )

655 x 435 x 610 ( 905 )

705 x 505 x 675 ( 990 )

Configuration

Bench-top

Bench-top

Bench-top

Max power ( W )

1600

4500

8000

Holding power ( W )

6000

2000

3500

Thermocouple type

R

R

R

Weight ( kg )

179

46

61

Power supply required per phase

380-415 3 phase + N 35A,200-220V 3 phase delta 60A,440-480V 3 phase no N 35A

220-240V single phase 36A,380-415V, 2 phasse + N, 18A

380-415V single phase 17.5,200-220 3 phase delta 30A,200-208V 3 phase + delta 38A,380-415V 3 phase delta 17.5A
