Blower 16” Standard Allegro Safety

Blowers Axial : 16” Standard Blower Allegro Safety

Specifications

Product Description

VENTILATION BLOWER, STANDARD

Part Number

9515

Style

AXIAL FAN 16” ( 40.6 cm )

General Description

Designed for applications requiring a large amount of output. This standard model blower has a ½ HP motor with an efficient six-blade impeller in a rugged metal housing. Certified to CSA Standard C22.2 No.113.

Construction

Complete unit epoxy powder coated in orange

Interchangeable flange for intake or exhaust side mounting

18 gauge cold rolled steel housing

Integrated carrying handles

Steel/chrome plated grill

Equipped with four rubber feet

Can be used with Adaptor Reducer ( PN : 9600-50 ) used with 8” ( 20.3 cm ) duct

Motor

HP

½ HP

Certifications

UL Recognized, CSA Certified

Voltage/Hz

115V AC, 60 Hz, Single Phase

RPM

1725

Current Draw

7.2 A

Cord

25’ ( 7.62 m ) 16/3 AWG, SJTW 90 C 300 V medium duty

Plug

NEMA 5-15 (Grounded three-prong)

Fan

Glass reinforced Polypropylene ( PPG ) six blade fan, with aluminum hub

Moving fan mounted 1⅝” ( 4.12 cm ) from grill for safety, grill gap-5/16”( 0.79 cm )

Ducting

Retractable, non-collapsible design

Single-ply, PVC coated, vinyl and polyester materials, temp. resistant up to 180 °F ( 82.2 °C )

Class 1 hard drawn spring steel wire helix that meets ASTM 227 specs

Blower Dimens

Length In ( cm )

Width In ( cm )

Height In ( cm )

Weight Lbs ( Kg )

18” ( 45.7 cm )

18” ( 45.7 cm )

19” ( 48.2 cm )

47 lbs ( 21.3 kg )

Flow Rates

( CFM calculated using 15’ ( 4.57 m ) of 16” ( 40.6 cm ) ducting )

Free Air CFM ( m³/hr )

One 90° Bend CFM ( m³/hr )

Two 90° Bends CFM ( m³/hr )

3400 ( 5776.63 )

2800 ( 4757.23 )

2300 ( 3907.72 )
