Sieve Shaker AS 200 Basic Retsch

Vibratory Sieve Shaker AS 200 Basic Retsch

Application Examples

Cement clinker, chemicals, coffee, construction materials, fertilizers, fillers, flours, grains, metals powders, minerals, nuts, plastics, sand, seeds, soils, washing powder, ....

Product Advantages

NEW : digital display of performance and time

Suitable for dry and wet sieving

Excellent separation efficiency even with short sieving times

Efficient electromagnetic drive

3-D throwing motion which ensures optimum use of the open sieve area and lets the sample move equally over the whole sieving surface

Sieve stack up to 510 mm height

Free adjustment of all process parameters ( time, performance )

Optional comfort clamping device

Optional evaluation software EasySieve

Maintenance-free

Easy operation, ergonomic design

Features

Applications

Separation, fractioning, particle size determination

Field of application

Agriculture, biology, chemistry / plastics, construction materials, engineering / electronics, environment / recycling, food, geology /metallurgy, glass / ceramics, medicine / pharmaceuticals

Feed material

Powders, bulk materials, suspensions

Measuring range*

20 µm - 25 mm

Sieving motion

Throwing motion with angular momentum

Max. batch / feed capacity

3 kg

Max. number of fractions

9 -17

Max. mass of sieve stack

4 kg

Amplitude

Digital, 1 - 100 % ( 0 - 3 mm )

Controlled amplitude

-

Time display

Digital, 1 - 99 min

Suitable for dry sieving

Yes

Suitable for wet sieving

Yes

USB interface

-

Including test certificate / can be calibrated

-

Suitable sieve diameters

100 mm / 150 mm / 200 mm / 203 mm ( 8" )

Max. height of sieve stack

510 mm

Clamping devices

"Standard", "comfort", each for wet and dry sieving

Protection code

IP 54 / IP 20

Electrical supply data

Different voltages

Power connection

1 phase

W x H x D

417 x 212 x 384 mm

Net weight

~ 35 kg

Standards

CE
