Motorized Atterberg Liquid Limits Machine SA-60F Gilson

Motorized Atterberg Liquid Limits Machine Gilson

Motorized Atterberg Liquid Limits Machine w/Counter (115V / 60Hz) Model : SA-60

Motorized Atterberg Liquid Limits Machine w/ Counter (230V / 50Hz) Model : SA 60F

Hand-Operated Atterberg Liquid Limits Machine Model : SA-61

Hand- Operated Atterberg Liquid Limits Machine w/Counter Model : SA-62

Description

Liquid Limit is the water content at which soil changes from a liquid to a plastic state, defined as a point where two halves of a soil sample flow together when jarred 25 times in a specified manner using a Liquid Limit machine.

Gilson offers motorized or hand-crank operated machines with either an automatic impact counter, or a cost-effective hand-crank model without counter. All models consist of a brass cup and carriage designed to control drop exactly 1cm onto a hard rubber base. Height of drop is adjusted by a nut at the rear of the cup carriage using the gauge at one end of the included plastic Casagrande Grooving Tool. The cup attaches to the carriage by a pin, for easy removal when cleaning or inspecting. All mechanical parts are machined from solid brass and rubber feet isolate the base from the work surface.

SA-60 Motorized Liquid Limit Machine with counter is most accurate with use of a special geared motor assuring proper operating speed of 1.9—2.1 drops per second. An on-off switch is provided.

SA-61 Hand Operated Liquid Limit Machine does not have a counter and is a more economical option.

SA-62 Hand Operated Liquid Limit Machine with counter offers a more automated, cost-effective option.

Features

Variety of motorized or hand-crank options to fit your application and budget

Complete control of drop to 1cm

Easily removable cup for cleaning or inspection

Included Items

SA-60 Motorized Liquid Limit Machine

Or

SA-61 Hand-Operated Liquid Limit Machine

Or

SA-62 Hand-Operated Liquid Limit Machine with Counter

Plastic Casagrande Grooving Tool

Optional Accessories

SA-66 Glass Plate

SAA-10P ASTM Liquid Limit Grooving Tool, Plastic-Casagrande

SAA-11 Liquid Limit Machines, Brass Cup with Mounting Holes

SAA-8 AASHTO Liquid Limits, Grooving Tool

SA-65 Accessory Set for Liquid/Plastic Limits

SAA-10 ASTM Liquid Limit Grooving Tool, metal-Casagrande

SAA-12 Liquid Limits Machines, Brass Cup with Holder

Meets Standard ( s )

AASHTO T 89 , AASHTO T 90 , ASTM D4318

Specifications

SA-60 , SA-60F Dimensions  12 x 7.5 x 6 in ( 305 x 191 x 152 mm ), L x W x H Estimated Shipping Weight, lb ( kg )  16 ( 7 )

SA-61 Dimensions  6.5 x 6 x 5 in ( 165 x 152 x 127 mm ), L x W x H Estimated Shipping Weight, lb ( kg )  5 ( 2 )

SA-62 Dimensions  6.5 x 7 x 5 in (165 x 178 x 127 mm), L x W x H Estimated Shipping Weight, lb ( kg )  5 ( 2 )

Meets Standard ( s )

AASHTO T 89 , AASHTO T 90 , ASTM D4318
