Viscometer DV1 Brookfield

Digital Viscometer DV1 Brookfield

A continuous sensing capability for rapid viscosity measurement makes this economical digital viscometer a standout. Measures viscosity and temperature simultaneously ( with an optional temperature probe ). With its timed measurement function, data can easily be sent to a PC or printer. Optional software allows the DV-I Prime to collect, analyze and record test data.

Features & Benefits

PC Interface for use with optional Wingather SQ Software and output connection to printer

Available as a choice of multiple languages: English, French, German, Portuguese, Russian, Spanish

Simplified user interface for more direct access to features

Direct access to time measurement function ( time to torque, time to stop )

Temperature off-set capability to ±5 °C

Senses and displays continuously :

- Viscosity ( cP or mPa·s )

- Temperature ( °C or °F ) ( OPTIonAL )

- % Torque

- Speed ( rpm )

- Spindle used

Torque measurement accuracy : 1 % of full scale range

Repeatability: 0.2 % of full scale range

Select all functions from user-friendly keypad

Choice of 18 rotational speeds

Optional RTD temperature probe

Auto-zero function to ensure precision torque measurement

Auto-range function to define full scale range ( FSR ) for all spindle/speed combinations

Warns of under- or over-range torque measurement condition

Printing to Dymo® capability

Timed Stop feature to measure viscosity at precise user specified time interval

Time to Torque feature to measure the time interval for sample to reach user defined torque value

Compatible with all Brookfield accessories

NIST traceable viscosity standards available

DV1MLV

1*

2M      .3-100                        18

DV1MRV

100

13M    .3-100                        18

DV1MHA

20

26M    .3-100                        18

DV1MHB

800

104M  .3-100                        18
