Hotplate Stirrer MSH-20A & MSH-30A Daihan Scientific

Premium Hotplate Stirrer MSH-A Daihan Scientific

DAIHAN Premium Hotplate Stirrer, “MSH-A”, Ceramic-Coated Plate, up to 380 ℃, 1,500 rpm, with Certi. & Traceability

Built-in Linearity PWM Controller, Superior Temp. Uniformity, Precise Control of Temp. & RPM, 180 ×180 mm or 260 × 260 mm

■ with Certificate & Traceability : Controlled by Serial Number, Certificate, Delivery-information, and Traceable Data base System

■ Superior Temp. Uniformity : Less than 10 % on the Plate at Ambient Temp.

■ Superior Linearity for Temp. Control & Stirring Speed

■ Ceramic Coated Plate-Chemical / Acid Resistance

■ CE Certified

■ PL ( Product Liability ) Insurance

� Excellent for Sample Drying and most General Lab Heating Applications

� Superior Temperature Uniformity : Less than 10 % on the Plate at Ambient Temp.

� Superior Linearity for Temperature Control & Stirring Speed by Specially Designed Control Circuitry.( PWM Control )

� Smart Design of Body made by Aluminum Die - Casting ( MSH-20A )

� Ceramic Coated Plate - Chemical / Acid Resistance

� Maximum Temperature of 380 ℃

Specification

Model

180 × 180 mm Plate-type

260 × 260 mm Plate-type

“MSH- 20A”

“MSH- 30A”

Body

Powder Coated Aluminum

Powder Coated Steel

Plate

Ceramic Coated Aluminum ( Chemical / Acid Resistance, Easy to Clean )

Stirring Capa. & Motor Rating

Max. 20 Lit.,  9 / 4 W

Speed Range

Max. 1,500 rpm

Temp. Range

Max. 380 ℃

Temp. Uniformity

Specially Designed Heating Module : Temp. Difference 10 % less

Heating Power/Consumption

600 W

1.2 kW

Controller

Superior Linearity PWM Controller

Stirring Bar

3cm bar-included, Usable : up to 5cm bar

Permissible Temp. & RH %

Ambient +5 ~ 50 ℃, 85 % RH

Dimension & Weight

206 × 307 × h99 mm,  2.8 kg

286 × 387 × h99 mm, 3.3 kg

Packing Size & Gross Weight

400 × 280 × h200 mm,   5 kg

430 × 320 × h200 mm, 5 kg

Power Supply & Cord/ Plug*

1 Phase, AC 120 V, 60 Hz or AC 230 V, 50 / 60 Hz, with Cord / Plug
