Homogenizer HG-15D Daihan Scientific

Homogenizer Digital HG-15D Daihan Scientific

DAIHAN-brand Homogenizer with Remote Digital Controller, “HG-15D”, 2,000~2,7000 rpm with Microprocessor Digital-Control, High-Efficiency Dispersing Tools, Back Light LCD, 1~2,500 ml

■ with Certificate & Traceability :

    Controlled by Serial Number, Certificate, Delivery-information, and Traceable Data base System

■ Patented Jog-Shuttle Control System

■ PL ( Product Liability ) Insurance

■ CE Certified

� Useful for All Dispersing and Homogenizing Applications

� Designed for Liquid and Tissue Samples

� High Speed / High Quality / Low Noise : Max. 27,000 RPM ( without load )

� Remote Digital Controller : Fully Digital Controlled by Using Microprocessor

� Speed & Power Control Optimized for a Sample

� LCD of Speed ( RPM ) and Power Bar Graph

� High Efficiency Dispersing Tool made of Stainless steel and PTFE

Specification

Model

Homogenizer Package-Set “HG - 15D-Set”

Speed Range & Resolution

2,000 ~ 27,000rpm ( without load ), 10 rpm-Control

Working Range

1 ~ 2,500 ml

Motor Rating (Input / Output)

Input : 300 W ,  Output : 160 W

Timer & Alarm

10 sec ~ 15 min, Timer-end Alarm

Display

Digital LCD with Back - Light Function

Controller

Digital Feedback Controller ( Remote Type )

Safety Device

Over Load & Over Heat Protector

Usable Dispersing Tool

Φ8 mm Stator “HT1008”, Φ10 mm Stator  “HT1010”,

Φ18 mm Stator “HT1018”, Φ25 mm Stator “HT1025”

Material

Aluminum Die-casting and ABS-Unit, Stainless steel ( ＃304 )-Tool

Permissible Temp. & Moisture

Ambient +5 ~ 50 ℃, 85 %

Extension Arm Size

Φ12.7 × L250 mm

Dimension & Weight

60 × 75 × h215 mm, 2.5 kg

Packing Size & Gross Weight

580 × 340 × h230 mm, 6 kg

Power Consumption

160 W

Power Supply & Cord Plug

1 Phase, AC 120V, 60Hz or AC 230V, 50 / 60Hz
