Water Bath WHB-6,WHB-11,WHB22 Daihan Scientific

Water Bath WHB Series Daihan Scientific

DAIHAN-brand Digital High Temperature Oil Bath, “WHB”, 6-/11-/22-Lit., with Certi. & Traceability with 1×Stainless steel Flat Lid, Digital Fuzzy Control System, Back Light LCD, up to 250 ℃, ±1.5 ℃

■ with Certificate & Traceability :

    Controlled by Serial Number, Certificate, Delivery-information, and Traceable Data base System

■ Digital Fuzzy Control System Implementing Superior Temperature Accuracy

■ Patented Jog-Shuttle Control System and Digital LCD with Back - Light Function

■ CE Certified

■ PL ( Product Liability ) Insurance

� Corrosion Resistant 304 Stainless steel Bath having 1.2 mm Thickness and Ceramic Fiber

     Insulator of 50mm Thickness are used for an application at High Temperature

� User's Self-Compensation Function to Control Difference between Real Temperature and Indicated Temperature

� Storage Function for the Set Values of Temperature and Timer

� Alarm Function : Error Status and Timer-end.

� Digital Timer Function : ‘Delay Time’ and ‘Operation Time’ can be Controlled.

� Locking Mode Supported for Experimental Safety (Input to Jog-Shuttle can be Disabled)

Specification

Capacity & Model

6 Lit. “WHB-6”

11 Lit. “WHB-11”

22 Lit. “WHB-22”

Temp. Range & Accuracy

Ambient + 5 ℃ to 250 ℃,  ±1.5 ℃

Temp. Uniformity & Probe

±3.0 ℃, PT100

Heating Power

1.5 kW

2.0 kW

2.5 kW

Timer & Alarm

99 hr 59 min ( Delay & Continuous run ), Error status & Timer-end

Display

Digital LCD with Back - Light Function

Controller

Digital Fuzzy Controller with Jog-Shuttle Switch ( Turn+Push )

Safety Circuit

Over-Temp./-Current protection, Sensor Error Detection

Material

Stainless steel (＃304 )-Internal,  Powder Coated steel-External,

50 mm Thickness Ceramic Fiber-Insulation

Lid

Stainless steel Flat Lid Included

Drain Valve

Mounted

Dimension ( W × D × H )

Effective Space

270 ×180 × h 110 mm

300 × 250 × h 110 mm

400 × 300 × h 140 mm

Internal

270 × 180 × h 150 mm

300 × 250 × h 150 mm

400 × 300 × h 180 mm

External

425 × 305 × h 340 mm

425 × 375 × h 340 mm

525 × 425 × h 370 mm

Packing Size &

470 × 400 × h 500 mm

600 × 490 × h 500 mm

600 × 490 × h 500 mm

Gross Weight

23 kg

25 kg

39 kg

Power Supply & Cord / Plug

1 Phase, AC 120 V, 60 Hz or 230 V, 50 / 60 Hz
