Nanaboshi Connector NJW Series Plug Type S and Type G
Perhatian!
Spesifikasi Nanaboshi Connector NJW Series Plug Type S and Type G
•Feature
1.The 5-key system guide makes for smooth combination.
2.A one-touch lock mechanism is used in the combination system.[NRW]
3.This product has received standards certifications.
•Material and Finish
1.Shell : - Material : Zinc Alloy ; Aluminum alloy
- Finish : Specially chemical finish
2.Insulator : -Material : Shyntetic resin
3.Contact : - Material : Copper Alloy
- Finish : Silver plating ; Gold plating
4.Packing : - Material : Shyntetic rubber
•Plug S Type
1.NJW-16*-PF_
- Number of contacts : 3,5,8
- A : 22
- B : 58
2.NJW-20*-PF_
- Number of contacts : 2,3,4,5,7,10,12,14
- A : 26
- B : 60
3.NJW-24*-PF_
- Number of contacts : 2,3,4,5,10,14,16,21,24
- A : 30
- B : 67
4.NJW-28*-PF_
- Number of contacts : 16,24,31,37
- A : 34
- B : 72
1.NJW-32*-PF_
-Number of contacts : 3,4
- A : 44
- B : 101
•Plug G Type
1.NJW-16*-PM_
- Number of contacts : 3,5,8
- A : 22
-B : 58
2.NJW-20*-PM_
- Number of contacts : 2,3,4,5,7,10,12,14
- A : 26
- B : 60
3.NJW-24*-PM_
- Number of contacts : 2,3,4,5,10,14,16,21,24
- A : 30
- B : 67
4.NJW-28*-PM_
- Number of contacts : 16,24,31,37
- A : 34
- B : 72
5.NJW-32*-PM_
- Number of contacts : 3,4
- A : 44
- B : 101
Orde Cording :
NRW : Series designation
20 : Shell Size
7 : Number of Contact
PM : Type of shapes if connector
_ : Symbol repsenting the outher diameter of the cable
