Rotor Desicant Dehumidifier RDH

Rotor Desicant Dehumidifier RDH

Model

Description

Specifications

Dimensions

RDH-180P

Desiccant dehumidifier

· Dehumidifying capacity : 0.5 kg/h

* Unit size :

12 L/day ( 20 ℃,60 % )

· Dry air flow :180 m³/h; Wet air flow : 60 m³/h

250 * 224 * 495 mm

· Applied temperature from -10 ℃ to 45 ℃

* Packing size :

· Maximum Input Power : 1000 w

350 * 300 * 550 mm

· Heater current : 4 A

· Supply fuse 220-240V/ 50Hz

· Stainless steel 304

· Operation indicator, timer switch

· Washable rotor imported from Sweden

· Built-in heat recovery

· Automatic faults detecting system, long lifespan

· Approval : CE/CCC/RoHs

RDH-200P

Desiccant dehumidifier

· Dehumidifying capacity : 0.7 kg/h

* Unit size :

16.8 L/day ( 20 ℃,60 % )

· Dry air flow : 210 m³/h; Wet air flow: 80 m³/h

250 * 224 * 695 mm

· Applied temperature from -10 ℃ to 45 ℃

* Packing size :

· Maximum Input Power : 1300 w

380 * 350 * 850 mm

· Heater current : 4.5 A

· Supply fuse 220-240 V/50 Hz

· Stainless steel 304

· Operation indicator, timer switch

· Washable rotor imported from Sweden

· Built-in heat recovery

· Automatic faults detecting system, Long lifespan

· Approval : CE/CCC/RoHs

RDH-550P

Desiccant dehumidifier

· Dehumidifying capacity : 3 kg/h

* Unit size :

72 L/day ( 20 ℃,60 % )

· Dry air flow : 500 m³/h; Wet air flow : 160 m³/h

540 * 470 * 450 mm

· Applied temperature from 0 ℃ to 45 ℃

* Packing size :

· Maximum Input Power: 6000 w

560 * 480 * 510 mm

· Heater current : 10 A

· Supply fuse 220-240 V/50 Hz

· Stainless steel

· Operation indicator,timer switch

· Washable rotor imported from Sweden

· Built-in heat recovery

· Automatic faults detecting system, Long lifespan

· Approval : CE/CCC/RoHs

RDH-1500P

Desiccant dehumidifier

· Dehumidifying capacity : 10 kg/h

240 L/day ( 20 ℃,60 % )

· Dry air flow : 1500 m³/h ; Wet air flow : 580 m³/h

· Applied temperature from 0 ℃ to 45 ℃

· Maximum Input Power : 14.7 KW

· Heater current : 50/25 A

· Supply fuse 3 * 230/400 V50 Hz

· Stainless steel 304

· Operation indicator,timer switch

· Washable rotor imported from Sweden

· Built-in heat recovery

· Automatic faults detecting system, Long lifespan

· Approval : CE/CCC/RoHs
