HUMAN VIBRARION

·    For Hand-Arm vibration to ISO5349 and ISO/TR 18570, whole-body vibration to ISO2631 and ship vibration to ISO 20283-5

·    Acceleration, velocity and displacement ranges for machine vibration

·    Display of running and interval RMS, maximum RMS (MTVV), vibration dose value (VDV), vector sum, peak and maximum peak value

·    Fourth channel for SEAT measurements at driver seats

·    3-channel FFT for the detection of main frequencies

·    TEDS support for automatic sensor detection

·    Memory for saving measurements by keypress

·    Data logger function for RMS or peak values

·    USB interface for data transfer to a PC

·    Excel macro for the calculation of daily exposure A(8) and report generation

·    Compact design

·    Simple operation

Measuring inputs

4 Low Power IEPE inputs with TEDS for sensors with 8 to 1200 mV/g

Human vibration weighting filters

Wb, Wc, Wd, Wh, Wj, Wk, Wm and Wp to ISO8041

Band filters

Human vibration: 0.4 - 100 Hz; 6.3 - 1259 Hz
Acceleration: 0.1 - 1500 Hz; 1 - 1000 Hz
Velocity: 1 - 100 Hz; 2 - 1000 Hz; 10 - 1000 Hz
Displacement: 5 - 250 Hz

Frequency analysis (FFT)

125 lines for X/Y/Z, peak spectrum of acceleration

Data memory

10000 manually saved measurements, 100 log files of 32000 measurements each, 1000 FFTs, each with date, time and comment

Display

OLED, 128 x 160 pixels, colored

Batteries

3 accumulators HR03 or alkaline cells LR03 (AAA), 10 -14 hours operation
