CSE P Series Junction Boxes
Update Terakhir
18-06-2019
Dilihat Sebanyak
3 kali
Lokasi
Jawa Timur - Sidoarjo
Harga
Kontak Kami
Bagikan
+ Penawaran
Perhatian!
Perusahaan ini terdaftar sebagai Free Member. Hindari melakukan pembayaran sebelum bertemu penjual atau melihat barang secara langsung. COD (Cash On Delivery) atau bertemu langsung dengan penjual merupakan metode transaksi lebih aman.
Spesifikasi CSE P Series Junction Boxes
Detail CSE P Series Junction Boxes
CSE P series junction boxes
The CSE - P enclosures are normally used in the chemical and petrochemical plants, off-shore platforms, refineries and any other industry where hazardous atmospheres (gas and combustible dust) are potentially present.
The CSE - P enclosures range has been designed to meet the main requirements of power distribution, monitoring and signalling, and other electrical functions inside the hazardous area of the plant
Function
The CSE - P enclosures are normally used form the following main applications:
- control stations
- emergency call units
- instrument housings
- circuit breakers
- switches and changeover switches
- lighting controls - terminal boxes
- electrical housing
- battery container
The CSE P A enclosures are available in different sizes so to create a large and modular range with different heights.
The CSE - P enclosures, jointed together through dedicated flanges, can become a large panel, maintaining the original IP protection. Starting height 90 mm. the CSE - P series can be equipped with operators (pilot lights, push buttons, switches, ect.) on cover.
Construction
The materials used to manufacture the CSE - P series have been studied to grant the maximum protection against the highly corrosive agents present in these industries:
- body and cover in glass-reinforced polyester (GRP) black coloured to provide the maximum UV protection and loaded with carbon, to eliminate the risk of ignition sources through static induced sparking resistivity.
- antiloosening screws on cover in stainless steel AISI 316
- gasket on cover in silicone
- internal fixing screws in stainless steel
Accessories
To CSE - P enclosures can be completed with the following accessories:
- internal earth continuity plate in galvanized steel, copper or brass
- internal mounting plate in galvanized steel or stainless steel
- mounting brackets in stainless steel
- internal and external earth screws in stainless steel AISI 316
- external hinges in thermoplastic material
Protection certificate number: IMQ 13 ATEX 000
marking:
` II 2GD Ex e ia IIC T6 Gb Ex tb IIIC T85°C Db (terminal boxes)
` II 2GD Ex d e mb IIC T6 Gb Ex tb IIIC T85°C Db (control stations)
ambient temperature: -40°C +60°C
degree of protection: IP66
conformity: Directive ATEX 94/9/EC
standards: EN60079-0 / EN60079-1 / EN60079-7 / EN60079-11 / EN 60079-18 / EN60079-31
category: suitable for Zone 1 – 21 (gas) and Zone 2 – 22 (dust)
