OPTIONS
-
Combined online/offline use
-
Compact size and low weight
-
Bi-directional communication
-
Standard depth range 3000 m
-
Long-distance FSK-telemetry (>10000 m)
-
Low power consumption
-
Battery operated Underwater Unit, max. voltage of 5 V at the conductor cable
-
Electronics operate from -40°C up to +85°C
-
EC-conformity (CE) EN 50081-1, EN 50082-1
| TECHNICAL DATA | |
|---|---|
| Measuring range | 0 ... 3000 dbar ± 0.1% f.s. |
| Data memory | 4 MByte, sufficient for 290 hours recording |
| Data sampling rate | 1 Hz (one data set per second) |
| Telemetry connector | SUBCONN IL 2 M |
| Dimensions | 45 mm dia. x 230 mm |
| Weight | 1 kg |
| Material | Titanium |
| Hand Unit | Plastic housing, splash-proof (IP 65), battery powered, LC-display 4 x 20 characters, interface for PC (RS-232) |
| ORDERING INFORMATION | |
|---|---|
| Products | |
| 450 400 | Depth Meter for online/offline operation incl. hand unit, battery charger and OceanLab 3 software |
