Radio Rig Icom IC V8000
Gambar Produk
Radio Rig Icom IC V8000
Pengiriman
1 Hari Setelah Pembayaran
Lokasi
Harga
Kontak Kami
Dilihat Sebanyak
40 kali
Update Terakhir
17-03-2017
Bagikan
+ Penawaran
Perhatian!
Perusahaan ini terdaftar sebagai Free Member. Hindari melakukan pembayaran sebelum bertemu penjual atau melihat barang secara langsung. COD (Cash On Delivery) atau bertemu langsung dengan penjual merupakan metode transaksi lebih aman.
Spesifikasi Radio Rig Icom IC V8000
Specifications Radio Rig Icom IC V8000
| General | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Frequency coverage Transmit Recieve |
144 – 148 MHz 136 – 174 MHz* *Guaranteed 144 – 148 MHz only Frequency ranges are depending on version |
|||||||||
| Mode | FM (F3E, F2D) | |||||||||
| No. of memory channels | 207 (including 6 scan edges, and 1 call channel) | |||||||||
| Operating temperature range | -10°C to +60°C; +14°F to +140°F | |||||||||
| Frequency stability | ±10 ppm (-10°C to +60°C) | |||||||||
| Power supply requirement | 13.8 V DC ±15% (negative ground) | |||||||||
| Current drain |
|
|||||||||
| Antenna connector | SO-239 (50Ω) | |||||||||
| Dimensions (projections not included) |
150(W) × 50(H) × 150(D) mm; 529/32(W) × 131/32(H) × 529/32(D) in |
|||||||||
| Weight | 1.09 kg; 2.2 lb | |||||||||
| Transmitter | |
|---|---|
| Output power (continuously adjustable) |
75, 25, 10, 5 W selectable |
| Maximum frequencydeviation (wide/narrow) | ±5.0/±2.5 kHz |
| Spurious emission | Less than -60 dB |
| Microphone connector | 8-pin modular (600Ω) |
| Receiver | |
|---|---|
| Receive system | Double-conversion superheterodyne system |
| Intermediate frequencies 1st 2nd |
21.7 MHz450 kHz |
| Receive Sensitivity | 0.15 µV (at 12dB SINAD) |
| Selectivity (wide/narrow) | More than 6/3 kHz at -6dB Less than 14/9 kHz at -60 dB |
| Spurious and image rejection ratio | 75dB typical |
| Intermodulation rejection | 75dB typical |
| Audio output power (at 13.8 V DC) |
More than 2.0W at 10% distortion with an 8Ω load |
| Ext SP connector | 3-connector 3.5 (d) mm (1/8“)/8Ω |
All stated specifications are subject to change without notice or obligation.
Supplied accessories
- Hand microphone*
- DC power cable
- Spare fuse
- Mobile mounting bracket kit
- Microphone hanger*
