Accuracy:±2 % of reading plus 0.01 NTU from 0 to 40 NTU;
±10 % of reading from 40 to 1000 NTU based on Formazin primary standard (at 25 °C)
±10 % of reading from 40 to 1000 NTU based on Formazin primary standard (at 25 °C)
Calibration Method:For Formazin and Stablcal:
20 NTU from 0 to 40 NTU; at 20 FNU and 600 NTU for full range
Custom calibration for up to 6-point calibrations
Degrees 0 - 100 mg/L
SDVB 0 - 1000 NTU
20 NTU from 0 to 40 NTU; at 20 FNU and 600 NTU for full range
Custom calibration for up to 6-point calibrations
Degrees 0 - 100 mg/L
SDVB 0 - 1000 NTU
Certifications:CE compliant
US FDA accession number: 1420493-000 EPA version, 1420492-000 ISO version
Complies with IEC/EN 60825-1 and to 21 CFR 1040.10 in accordance with Laser Notice No. 50)
Australian ACMA Marking
US FDA accession number: 1420493-000 EPA version, 1420492-000 ISO version
Complies with IEC/EN 60825-1 and to 21 CFR 1040.10 in accordance with Laser Notice No. 50)
Australian ACMA Marking
Communication:Link2sc and RFID
Dimensions (H x W x D):195 mm x 409 mm x 278 mm
Display:7" WVGA (800 x 480) color TFT-LCD with touch screen
Enclosure Construction:PC/ABS Blend Plastic
Light Source:Class 2 laser product, with embedded 650 nm (EPA 0.43 mW) or Class 1 laser product, with embedded 850 nm (ISO), max. 0.55 mW (complies with IEC/EN 60825-1 and to 21 CFR 1040.10 in accordance with Laser Notice No. 50)
Operating Humidity:80% at 30 °C (non condensing)
Operating Temperature Range:10 to 40 °C (50 to 104 °F)
Power Requirements (Hz):50/60 Hz
Power Requirements (Voltage):100 - 240 VAC
Range:EPA:
0 to 700 NTU / FNU / TE/F / FTU
0 to 100 mg/L
0 to 175 EBC
ISO:
0 to 1000 NTU / FNU / TE/F / FTU
0 to 100 mg/L
0 to 250 EBC
0 to 700 NTU / FNU / TE/F / FTU
0 to 100 mg/L
0 to 175 EBC
ISO:
0 to 1000 NTU / FNU / TE/F / FTU
0 to 100 mg/L
0 to 250 EBC
Regulatory:DIN EN ISO 7027
Repeatability:<40 NTU: Better than 1% of reading or ±0.002 NTU on Formazin at 25 °C (77 °F), whichever is greater
>40 NTU: Better than 3.5% of reading on Formazin at 25 °C (77 °F)
>40 NTU: Better than 3.5% of reading on Formazin at 25 °C (77 °F)
Resolution:0.0001 NTU / FNU / TE/F / FTU / EBC / mg/L
Response Time:Signal averaging off: 7 seconds
Signal averaging on: 10 seconds (when averaging time is 5 seconds)
Signal averaging on: 10 seconds (when averaging time is 5 seconds)
Sample Temperature:4 to 70 °C (39 to 158 °F)
Storage Conditions:-30 to 60 °C (-22 to 140 °F)
Stray Light:<10 mNTU
Units:NTU, FNU, TE/F, FTU, EBC;
mg/L if calibrated with Degrees calibration curve
mg/L if calibrated with Degrees calibration curve
Warranty:1 year
Weight:5.29 lbs. (2.4 kg)
