GW INSTEK GOM-804 & GOM-805
Perhatian!
Spesifikasi GW INSTEK GOM-804 & GOM-805
General
|
NOTE |
Specifications are ensured only for GOM-804/805 at least 30 minute of warm-up time and Operating Temperature Specification: 18~28˚C |
|
Display |
3.5'(320 x 240) TFT LCD |
|
Memory |
20 sets for panel setting |
|
Power Source |
AC 100 - 240 V, 50/60Hz |
|
Comsumption |
25VA (max.) |
|
Dimension |
223(W) x 102(H) x 283(D) mm |
|
Weight |
Approx.3kg(max.) |
Specifications
|
MODEL |
GOM-804 |
GOM-805 |
|||||||||
|
DISPLAY |
|||||||||||
|
|
50,000 counts |
||||||||||
|
SAMPLING RATE |
|||||||||||
|
Slow |
10 readings / s |
||||||||||
|
Fast |
60 readings / s |
||||||||||
|
RESISTANCE MEASUREMENT |
|||||||||||
|
Range / Test current (fixed) |
|
||||||||||
|
Accuracy |
50mΩ : ± (0.1% of reading + 0.02% of range) |
||||||||||
|
|
500mΩ ~ 50Ω : ± (0.05% of reading + 0.02% of range) |
||||||||||
|
|
500Ω ~ 500kΩ : ± (0.05% of reading + 0.008% of range) |
||||||||||
|
|
5MΩ : ± (0.2% of reading + 0.008% of range) |
||||||||||
|
Resolution |
1µΩ, 10µΩ, 100µΩ, 1mΩ, 10mΩ, 100mΩ, 1Ω, 10Ω, 100Ω |
||||||||||
|
TEMPERATURE |
|||||||||||
|
Range |
-50˚C ~399.9˚C |
||||||||||
|
Accuracy |
-10˚C ~40˚C : 0.3% ± 0.5˚C ; Other : 0.3% ± 1.0˚C |
||||||||||
|
Resolution |
0.1˚C |
||||||||||
|
DRY CIRCUIT |
|||||||||||
|
|
----- |
Open circuit less than 20mV; For 500mΩ, 5Ω, 50Ω range only |
|||||||||
|
DRIVE MODE |
|||||||||||
|
DC+/DC- |
----- |
Yes |
|||||||||
|
Pulsed |
----- |
Yes |
|||||||||
|
PWM |
----- |
Yes |
|||||||||
|
Zero |
----- |
Yes |
|||||||||
|
OTHER FUNCTIONS |
|||||||||||
|
|
Trigger – Internal, Manual, External、Math – ABS, REL, %, TC、Hi / Lo |
||||||||||
|
|
Average 2 ~ 10 times、Measured delay、Go / No-Go、TC for Transformer |
||||||||||
|
|
Diode、Continuity beeper、Sorting (only for GOM-805) |
||||||||||
|
INTERFACE |
|||||||||||
|
USB |
Standard |
Standard |
|||||||||
|
RS-232C |
Standard |
Standard |
|||||||||
|
HANDLER/SCAN/EXT I/O |
Standard |
Standard |
|||||||||
|
GPIB |
Option |
Standard |
|||||||||
Features
-
50,000 counts
-
3.5” (320 x 240) TFT LCD display
-
High accuracy of 0.05% precision
-
1Amp test current, 1µΩ resolution
-
Fast measurement of 60 readings per second
-
Four wire resistance measurement
-
Temperature compensation measurement function
-
Delayed measurement
-
20 sets of panel setting memory
-
Dry circuit (GOM-805 only)
-
Drive modes: DC+/DC-, Pulsed, PWM, Zero (GOM-805 only)
-
Interface: USB device, RS-232C, Handler/Scan/EXT I/O, and GPIB (option)
