CONSTANT DIGITAL CLAMP METER ADC 600
Perhatian!
Spesifikasi CONSTANT DIGITAL CLAMP METER ADC 600
- 42mm jaw opening
- DMM function
- Low battery indication
- Only figure ”1” for over range indication
- Negative polarity indication
| Function | Range | Accuracy |
| AC Current | 200A | ±(1.9% rdg ± 5 dgts) |
| 600A | ±(1.9% rdg + 5 dgts) | |
| DC Current | 200A | ±(1.9% rdg ± 5 dgts) |
| 600A | ±(1.9% rdg + 5 dgts) | |
| AC Voltage | 600V | ±(1.2% rdg ± 5 dgts) |
| DC Voltage | 20V | ±(0.8% rdg ± 2 dgts) |
| 600V | ±(0.8% rdg + 2 dgts) | |
| Input Impedance | 10MΩ (AC and DC Voltage) | |
| Resistance | 2kΩ | ±(1.0% rdg + 2 dgts) |
| Diode | Read approximately forward voltage drop of the diode. | |
| Continuity | If continuity exists ≤ 50Ω, built in buzzer will sound. | |
| Display | 3½ digits, 1999 counts | |
| Battery | 9V | |
| Size / Weight | H213 x W75 x D32mm / Approx. 240g | |
| Standard Accessories | Test Leads, Soft Pouch, Battery, Manual |
|
