Total Station Topcon GTS 105N

Total Station Topcon GTS 105N

Total Station Topcon GTS-105N series total station combines the traditional Topcon rugged field-ready quality and accuracy with economical, compact design that is perfect for everyday measuring and positioning applications such as topo and construction layout.

The entry-level value choice is the GTS-105N. Built with legendary Topcon precision and durability, the GTS-105N provides the construction professional with a dedicated lay-out solution. Use the on-board software to layout points in the field, confident that with Topcon, you’ ll be right on target. or use any of Topcon’ s field controllers running one of our range of software packages tailored to the tasks you want to perform.

GTS-105N features include:

* Economical, value priced measuring solution
* Rugged, durable, water resistant design
* Two accuracies to choose from 2 " & 5 "
* Expanded, Full numeric keypad
* On board programs & 24, 000 point data storage
* Ideal as a construction stakeout total station
* Perfect when combined with FC field controller and software

SPECIFICATION :

Length 150mm
Objective lens diameter 45mm ( EDM: 50mm)
Magnification ( x) 30X
Image Erect
Field of view 1° 30
Resolving Power 3 "
Minimum focusing distance 1.3m Distance Measurement
1 Prism 2, 000m
3 Prisms 2, 700m
Accuracy ± ( 2mm + 2ppmxD) , m.s.e.
Measuring Time Fine Mode 1mm: 1.2 sec ( initial 4 sec.) , 0.2mm: 2.8 sec. ( initial 5 sec.) Angle Measurement
Method Absolute encoder reading
Detecting system H: 2 sides V: 1 side
Accuracy 5 " Display
Display Unit 2 Sides
Keyboard 12 keys Tilt Correction
Tilt Sensor Single axis
Method Liquid Type
Compensating Range ± 3'
Correction Unit 1arc sec Operating Time
Including distance measurement 9 h.
Angle Measurement Only 40 h. ( Bluetooth 0N: 25h)

GTS-105N Complete with:

* Unit Topcon Total Station
* 2 x Aluminum Tripod
* 1 x Prisma Polygon
* 1 x Range Pole
* 1 x Single Prism
* 1 x Cable Data
* 1 x Software Data
