MDJNR2020K15
Spesifikasi MDJNR2020K15
MDJNR2020K15
Kode MDJNR2020K15 merujuk pada produk External Turning Tool Holder (Gagang Pisau Bubut Luar) buatan produsen alat potong asal Taiwan, Echaintool (E CHAIN). Alat ini dirancang khusus untuk mesin bubut CNC maupun manual dengan sistem pencekaman tipe Double-Clamp (D-Type).
- M: Sistem pencekaman Double-Clamp (menggunakan klem atas dan pin penarik).
- D: Bentuk sisipan (insert) belah ketupat 55° (Tipe DNMG).
- J: Sudut potong holder sebesar 93°.
- N: Sudut bebas insert adalah 0° (Negative Insert).
- R: Arah pemotongan tangan kanan (Right-hand).
- 2020: Ukuran gagang (shank) sebesar 20 mm x 20 mm.
- K: Panjang total holder adalah 125 mm.
- 15: Menggunakan ukuran panjang tepi potong insert 15 mm (Cocok untuk tipe DNMG 1504 atau DNMG 1506).
Berdasarkan katalog resmi Echaintool, berikut adalah komponen pengunci (spare parts) yang digunakan untuk tipe MDJNR2020K15: [1]
- Shim (Tatakan): SMD-463
- Lock Pin (Pin Pengunci): LCS-619
- Clamp (Klem Atas): CP50-24
- Clamp Screw (Baut Klem): CS70-21
