unit of supply Main Girder 10 tonne x 21M Span & Endcarriage

 Area 1 (Mesin Roll - Assembling Area) OHC Existing 10t

  Crane Structure

 End Carriage

 Model                                  : DHF-L-E 220/3000

 Wheel diametre              : 220 mm

 Drive                                    :2 x 1,5 kW ; 20 m/min (ex. Taiwan)

 Box Structure                   :Material ASTM A36

 Wheel base                       :3000 mm

 Ruber Bumper                 :dia. 80 mm

 Quantity (Set)                  :1

 Girder

 Girder capacity (kg)                        :               10000

 Girder Span (m)                               :               21

 Design standard (structure)       :               DIN 15081

 Raw material structure                 :               ASTM A36

 Deflection                                          :1 / 750

 Model                                                  :Boxed Double Girder

 Rail                                                        : 44*44

 Walkway + safety handrail                          :               1 side along the gider

 Bolt Joint set                                     :               HTB

 Surface preparation                       :               Manual Brush

 Painting                                               :               JOTUN 120 micron

 Girder Weight (kg)                         :               9737

 Quantity (unit)                 :               1

 Crane Electrical

 Power                                                  :               3 Phase 380 V 50 Hz

 Traversing Control                          :               21 meter Festoon system (Track S1A)

 Traveling Control                             :               78 meter Rail conductor 3P 75A KYEC

 Control Method                              :               Push Button (Emergency + 6 Button)

 Main + Traveling Panel                 :               Contactor system + Inverter system (LS)

 Hoisting + Traversing Panel         :               Contactor system (Schneider)

 Rotary Lamp & Sirene                   :               Standard

 Safety Device                                   :               Emergency stop protection

                                                 Traversing & travelling limit switch

                                                 Rotary Lamp & Horn

 Runway Crane

 Material                              :               by Existing

 Runway Beam                  :               by Existing

 Konsol                                 :               by Existing

 Rail                                        :               by Existing

 IV. Labour

 Project Management                    :               1 Ls

 Runway & Rail Installation           :               2 x 78 mtr

 Erection + Installation                   :               1 unit OHC

 Delivery equipment to site                         :               1 Ls
