LIFT BARANG 4 LANTAI

  LIFT BARANG 4 LANTAI

Spesifikasi Konstruksi Baja

Rail LIFT BARANG                                            : Double Rail UNP 120 (2 Sisi)

Ukuran Sanggar                                                : 1500(panjang) x 1500(lebar) x 1800(tinggi) mm

Konstruksi Rangka Sanggar                          : UNP 120 - UNP 100 - UNP 80 - Siku 50

Konstruksi Dinding Sanggar                        : Wire Mess 4 mm

Konstruksi Dinding Sangggar                       : Wiremess 1000mm - 4 Lembar

Konstruksi Lantai Sanggar                             : UNP 100 dan Plat bordes 3 mm

Konstruksi Pintu Sanggar                              : Holo 35x35

Konstruksi Atap sanggar                                               : UNP 80 dan Plat Besi 2mm

Roda Baja untuk Rail                                       : 130 x 50 mm sebanyak 4 Buah

Spesifikasi Electrical

Kontrol Otomatis                                                             1 Lot

Panel Kontrol 40 x 50                                                      1 lot

Call Pusb Button                                                               1 lot

Limit Switch                                                                        1 lot

Spesifikasi Pengaman LIFT BARANG

Taichuan safety Device Made in Taiwan                                                 1 set

INSTALASI & FABRICATION LIFT BARANG CAPACITY 3 TON

Safety Device Fall Prevention

Automatic panel Control 2 Floor

ganti Roda Rail

Penambahan Pagar Luar

Penambahan Pagar Dalam

INSTALASI & FABRICATION LIFT BARANG CAPACITY 1 TON

Safety Device Fall Prevention

Automatic panel Control 2 Floor

ganti Roda Rail

Penambahan Pagar Luar

OVERHEAD CRANE HOIST 5 TON

Span Girder WF 500x200

Konstruksi Runway WF 300x150

Konstruksi Rail Nako 50x50

Crane Saddle, Motor Horm 0,75Kw, Roda 200

Electrical

MITSUBISHI ELECTRIC WIRE ROPE HOIST

Specification

Type : S-5-LM3

Capacity                               : 5 Ton

Lifting Height                     : 8 Meters

Lifting Speed                      : 6,7 Meters/min

Lifting Motor                      : 6,2 Kw

Traversing Motor             : 0,85 Kw

Warranty 12 Month

DAITO ELECTRIC WIRE ROPE HOIST DC PRO

Specification

Type                                      : CD5-6D

Capacity                               : 5 Ton

Lifting Height                     : 12 Meters

Lifting Speed                      : 8 mpm

Lifting Motor                      : 7,5 Kw

Tarversing Speed             : 20 mpm

Traversing Motor             : 0,9 Kw

Warranty 12 Month

OVERHEAD CRANE HOIST 5 TON - SINGLE GIRDER

Box Span Girder Cap. 5 Ton

Crane Rail 50x50 - Panjang 30m x 2

Crane Saddle - Motor Horm 0,75/0,25Kw - Wheel Saddle 220

Electrical Long Travel Conductor System 75A - Wireless

Electrical Travel Conductor 60A -Wire Less

MHE DEMAG ELECTRIC WIRE ROPE HOIST DC PRO

Specification

Type                                      : EKDR-Bas 5

Capacity                               : 5 Ton

Lifting Height                     : 6 Meters

Lifting Speed                      : 6/1 mpm

Lifting Motor                      : 5,8/1,0 Kw

Tarversing Speed             : 20/5 mpm

Traversing Motor             : 1,2/0,9 Kw

Warranty 12 Month
