LIFT BARANG 2 LANTAI

Spesifikasi Konstruksi Baja

Rail  LIFT BARANG                                                            : Double Rail UNP 150 ( 4 batang)

Ukuran Sanggar                                                : 1000(panjang) x 1000(lebar) x 2000(tinggi) mm

Konstruksi Rangka Sanggar                          : UNP 120 - UNP 100 - UNP 80 - Siku 50

Konstruksi  Dinding Sanggar                        : Plat Besi 2 mm x 1000 mm - 4 lembar

Konstruksi Dinding Sangggar                       : Wiremess 1000mm - 4 Lembar

Konstruksi Lantai Sanggar                             : UNP 100 dan  Plat bordes 3 mm

Konstruksi Pintu Sanggar                              : Holo 40 x 40

Konstruksi Atap sanggar                                               : UNP 80 dan Plat Besi 2mm

Roda Baja untuk Rail                                       : 160 x 50 mm sebanyak 4 Buah

Spesifikasi Electrical

Kontrol Otomatis                                                             1 Lot

Panel Kontrol 40 x 30                                                      1 lot

Call Pusb Button                                                               1 lot

Limit Switch                                                                        1 lot

Spesifikasi Pengaman LIFT BARANG

Taichuan safety Device Made in Taiwan                 1 set

Spesifikasi Konstruksi Sipil

Pembobokan Lantai 1200 (panjang)x 1200(Lebar) x 200(tinggi) mm

HITACHI ELECTRIC CHAIN HOIST(bersetifikat)

Spesifikasi

Type Hitachi Chain Hoist                                : 2FH

Capacity                                                               : 2000 Kg

Load Chain Diameter                                      : 10mm - 1

Hoisting Lifting Height                                    : 6 Meter

Hoisting Speed                                                  : 6,8 Meter/min

Hoisting Motor                                                  : 2.4 Kw

Voltage Source                                                 : 380V, 50 Hz,

OVERHEAD CRANE 3 TON

KonTRUKSI SPAN GIRDER SYSTEM BOX 22,4 METER CAP. 3 TON

END CARRIAGE SET (MOTOR HORM 0,4KW, RODA 150)

ELECRICAL CROSS TRAVEL - C TRACK SYSTEM

DAITO/NITTO ELECTRIC WIRE ROPE HOIST

Specification

Type                                      : CD1 3-6D

Capacity                               : 3 Ton

Lifting Height                     : 6 Meters

Lifting Speed                      : 8 Meters/min

Lifting Motor                      : 4,5Kw

Tarversing Speed             : 20 Meters/min

Traversing Motor             : 0,4Kw

Warranty 12 Month
