LIFT BARANG 3 LANTAI

Spesifikasi Konstruksi Baja

Rail  LIFT BARANG                                            : H BEAM 100

Ukuran Sanggar                                                : 2250(panjang) x 1800(lebar) x 1800(tinggi) mm

Konstruksi Rangka Sanggar                          : UNP 100 - UNP 80 - UNP80-UMP120

Konstruksi  Dinding Sanggar                        : Plat Besi 2 mm

Konstruksi Dinding Sangggar                       : Wiremess 900mm -

Konstruksi Lantai Sanggar                             : Plat besi 3 mm

Konstruksi Pintu Sanggar                              : UNP80 -UNP120

Roda Baja untuk Rail                                       : 160 x 50 mm sebanyak 4 Buah

Spesifikasi Electrical

Kontrol Otomatis                                             1 Lot

Panel Kontrol 40 x 30                                      1 lot

Call Pusb Button                                               1 lot

Limit Switch                                                        1 lot

Spesifikasi Pengaman LIFT BARANG

Taichuan safety Device Made in Taiwan                                                 1 set

Spesifikasi Konstruksi Sipil

Pembobokan Lantai 2300 (panjang)x 1500(Lebar) x 200(tinggi) mm

Mitsubishi Electric Wire Rope Hoist

Spesifikasi

Type Hitachi Chain Hoist                                : R-3-HK2

Capacity                                                               : 3000 Kg

Wire Rope Diameter                                       : 12 mm x 2

Hoisting Lifting Height                                    : 12 Meter

Hoisting Speed                                                  : 6 Meter/min

Hoisting Motor                                                  : 3,2 Kw
