LIFT BARANG 2 LANTAI

Spesifikasi Konstruksi Baja

Rail  LIFT BARANG                                            : Double Rail UNP 150 ( 4 batang)

Ukuran Sanggar                                                : 2300(panjang) x 1500(lebar) x 1800(tinggi) mm

Konstruksi Rangka Sanggar                          : UNP 120 - UNP 100 - UNP 80 - Siku 50

Konstruksi  Dinding Sanggar                        : Plat Besi 2 mm x 900 mm - 4 lembar

Konstruksi Dinding Sangggar                       : Wiremess 900mm - 4 Lembar

Konstruksi Lantai Sanggar                             : UNP 100 dan  Plat bordes 3 mm

Konstruksi Pintu Sanggar                              : Holo 40 x 40

Konstruksi Atap sanggar                                               : UNP 80 dan Plat Besi 2mm

Roda Baja untuk Rail                                       : 160 x 50 mm sebanyak 4 Buah

Spesifikasi Electrical

Kontrol Otomatis                                                             1 Lot

Panel Kontrol 40 x 30                                                      1 lot

Call Pusb Button                                                               1 lot

Limit Switch                                                                        1 lot

Spesifikasi Pengaman LIFT BARANG

Taichuan safety Device Made in Taiwan                 1 set

Spesifikasi Konstruksi Sipil

Pembobokan Lantai 2300 (panjang)x 1500(Lebar) x 200(tinggi) mm

HITACHI ELECTRIC HOIST

Spesifikasi

Type Hitachi Chain Hoist                                : 2 FH

Capacity                                                               : 2000 Kg

Load Chain Diameter                                      : 10 mm x 1

Hoisting Lifting Height                                    : 6 Meter

Hoisting Speed                                                  : 6.8 Meter/min

Hoisting Motor                                                  : 2.4 Kw
