ULTRA PURE WATER MACHINES
Perhatian!
Spesifikasi ULTRA PURE WATER MACHINES
CEDI MACHINES UNIT
Continuous Electrodeionization SystemThe performance of CEDI at
the various sites has been excellent.
CEDI continues to produce consistently high purity water over time.
Additionally, the rejection performance of conductivity and
specific ions is exceptionally high, predictable and stable over time.
The CEDI units are also able to consistently and predictably remove
weakly ionized species, such as carbon dioxide and silica.
This ability to consistently and predictably remove dissolved ionic
species as well as weakly ionized species, without the need for
chemical addition into the feed stream, sets CEDI apart from other
large scale commercial membrane processes.
The water quality that is produced by CEDI, especially in
combination with RO, is exceptional.
The level of purity achieved is generally at or near the standard
definition of high purity water.
When CEDI is compared to conventional ion-exchange systems,
the advantages are very strong: CEDI obviates the need for
on-site storage, use and ultimate disposal of Llarge quantities of
acid and caustic regenerating chemicals, eliminating associated safety,
regulatory and environmental concerns;
CEDI by operating in a continuous mode is inherently more stable and
less prone to upsets caused by batch operations.
SYSTEM SPECIFICATIONS
|
Product code |
MTC05 M01 |
MTC10 M01 |
MTC20 M01 |
MTC30 M01 |
MTC30 M02 |
MTC30 M03 |
MTC30 M04 |
|
Number of Models |
1 |
1 |
1 |
1 |
2 |
3 |
4 |
|
Min Flow (m³/hr) |
0.3 |
0.8 |
1.5 |
2.5 |
5 |
7.5 |
10 |
|
Nom Flow (m³/hr) |
0.5 |
1.13 |
2 |
3.5 |
6.5 |
9.5 |
12.5 |
|
Max Flow (m³/hr) |
0.75 |
1.5 |
2.5 |
4.5 |
9 |
13.5 |
18 |
|
Typical recovery |
90~95% |
90~95% |
90~95% |
90~95% |
90~95% |
90~95% |
90~95% |
|
Inlet |
1” |
1” |
1” |
1” |
1” |
2” |
2” |
|
Outlet |
1” |
1” |
1” |
1” |
1” |
2” |
2” |
|
Drain |
1/2” |
1/2” |
1/2” |
1/2” |
1/2” |
1” |
1” |
|
Inlet Max. Pre.(psi) |
100 |
||||||
|
Max Pre. Drop(psi) |
23~35 |
||||||
|
Max. Temperature |
<45℃ |
||||||
|
Voltage |
220/240/380VAC.50/60HZ |
380/480/575VAC,50/60HZ |
|||||
|
Amperage |
20 |
20 |
30 |
20 |
20 |
30 |
40 |
|
|
100×120×181 |
100×165×181 |
|||||
|
Ship Weight(kg) |
100 |
120 |
150 |
250 |
400 |
550 |
600 |
KETERANGAN LEBIH LANJUT........HUBUNGI KAMI DI : +6285730068486
CV. MITCHELL TECHNOLOGY INDONESIA
SPESIALISASI PERUSAHAAN DIBIDANG :
Design, Perakitan dan Pemasangan Mesin Pengolahan Air , Seperti :
1. MESIN ELECTRO-DEIONIZER/ DEMINERALIZER
2. MESIN DESALINASI AIR LAUT
3. MESIN IPAL & STP TEKNOLOGI MBR
RINCIAN SCOPE PEKERJAAN :
INSTALASI PENGOLAHAN AIR ( WTP, WWTP & STP ) :
A. Water-treatment (WTP)/ Pengolahan Air Baku, Seperti:
Air Baku yang tercemar limbah
Air Baku yang tercemar/ erupsi air laut/ air payau dan air bergambut
Pengolahan Air Laut Menjadi Air Tawar dan Siap Minum
B. Waste-WaterTreatment (WWTP) & Sewage Treatment Plan (STP)
Seperti Pengolahan Air Limbah :
Untuk Konsultasi Silahkan Hubungi kami…….
