Specification
| DC V | 600.0mV/6.000/60.00/600.0/600V (Input Impedance: 10MΩ, 100MΩ only 600mV) |±0.5%±2dgt (600.0mV/6.000/60.00/600.0V) |±0.8%±3dgt (600V) |
||||
| AC V | 6.000/60.00/600.0/600V (Input Impedance: 10MΩ) |±1.0%±3dgt (6.000/60.00/600.0V) |±1.5%±3dgt (600V) |
||||
| DC A | 600/6000µA/60/600mA/6/10A |±1.2%±3dgt (600/6000µA/60/600mA) |±2.0%±5dgt (6/10A) |
||||
| AC A | 600/6000µA/60/600mA/6/10A |±1.5%±4dgt (600/6000µA/60/600mA) |±2.2%±5dgt (6/10A) |
||||
| Ω | 600Ω/6/60/600kΩ/6/60MΩ |±1.0%±2dgt (600Ω/6/60/600kΩ/6MΩ) |±2.0%±3dgt (60MΩ) |
||||
| Continuity buzzer | 0 – 600Ω (Buzzer sounds below 100Ω) | ||||
| Diode Check | 2.8V Release Voltage:Approx. 0.4mA Test Current | ||||
| Capacitance | 40/400nF/4/40/400/4000µF | ||||
| Frequency | 10/100/1000Hz/10/100/1000kHz/10MHz | ||||
| DUTY | 0.1 – 99.9% (Pulse width/Pulse period) |±2.0%±2dgt (- 10kHz) |
||||
| Temperature | -50 – 300ºC (-58 – 572ºF) (with the use of Temperature probe 8216)
|
||||
| Display | 6040 Counts | ||||
| Withstand Voltage | AC 3700V / 1min. | ||||
| Applicable standards | IEC 61010-1 CAT III 300V Pollution degree 2 IEC 61010-1 CAT II 600V Pollution degree 2 IEC 61010-031 IEC 61326 |
||||
| Power Source | R6 (1.5V) × 2 (Auto-power-OFF within 15 minutes) | ||||
| Dimensions | 161(L) × 82(W) × 50(D)mm | ||||
| Weight | Approx. 280g | ||||
| Accessories | 7066A (Test leads) 8216 (K-type Temperature probe) 0.8A/600V (Ceramic Fuse) × 1  built-in10A/600V (Ceramic Fuse) × 1 built-inR6 × 2 Instruction Manual |
||||
| Optional | 7234 (Crocodile clip test lead) 9095 (Carrying case) |
||||
