Specification
| AC A | 40/300A ±1%rdg±4dgt [50/60Hz] (0 – 40A) |±2.5%rdg±4dgt [20Hz – 1kHz] (0 – 40A) |±1.5%rdg±4dgt[50/60Hz] (20 – 200A) |±2.5%rdg±4dgt
[20Hz – 1kHz] (20 – 200A) [50/60Hz] (200 – 300A) (200 – 300A) |
| DC A | 40/300A |±1%rdg±4dgt (0 – ±40A) |±1.5%rdg±4dgt (±20 – ±200A) |±3%rdg (±200 – ±300A) |
| Conductor Size | Ø24mm max. |
| Safety Standard | IEC 61010-1 CAT III 300V IEC 61010-2-032 |
| Frequency Response | DC, 20Hz – 1kHz |
| Withstand Voltage | 3700V AC for 1 minute |
| Power Source | LR-44 (1.5V) × 2 |
| Dimensions | 147(L) × 59(W) × 25(D)mm |
| Weight | 100g approx. |
| Accessories | 9090 (Carrying Case) LR-44 × 2 Instruction Manual |
| Optional | 8008 (Multi-Tran) (AC only) |
