Specification
| AC A | 200/600A (True RMS) |±1.5%rdg±4dgt[50/60Hz]
(CF<3) [40Hz – 1kHz] (Sine wave) |
| AC V | 200/600V (True RMS)
(CF<3) [50/60Hz] [40Hz – 1kHz] |
| Ω | 200Ω |±1.2%rdg±4dgt |
| Continuity buzzer | buzzer sounds below 30±20Ω |
| Conductor Size | Ø33mm max. |
| Safety Standard | IEC 61010-1 CAT III 600V Pollution Degree 2 IEC 61010-2-031 |
| Frequency Response | 40Hz – 1kHz |
| Withstand Voltage | 5550V AC for 1 minute |
| Power Source | 6F22 (9V) × 1 |
| Dimensions | 208(L) × 91(W) × 40(D)mm |
| Weight | 400g approx. |
| Accessories | 7066A (Test leads) 9079 (Carrying case) 6F22 × 1 Instruction Manual |
| Optional | 8008 (Multi-Tran) |
