NEXEN MECHANICAL TORQUE LIMITER / BALL MTL - PMT SERIES

This range of mechanical torque limiters are available as multi or single position, detent/ball interface torque overload units. They are designed to shield drive and driven parts from damage that results from torque overloads. Backlash free torque transmission is achieved with a help of a range of balls that are embedded in hardened dents within the interface of the units.

The potential torque ranges from 40-24,000 in-lbs and the overloads can be flagged with the help of a proximity sensor, which alerts the drive to shut down. For applications of high speed, there is a complete disengagement version that frees the wheels in the event of an overload. Re engagement is completed manually by jogging into position.

P R O D U C T - D E S C R I P T I O N
975005-005 .......MTL15-PMT-SP-0.500-5/15
975008-040........MTL15-PMT-SP-0.625-20/40
975206-033........MTL30-PMT-SP-0625-20/60
975006-005........MTL15-PMT-MP-0.625-5/15
975024-005........MTL15-PMT-MP-0.625-5/15
975207-010........MTL30-PMT-SP-0.750-10/30
975405-010........MTL60-PMT-SP-0.750-10/30
975424-010........MTL15-PMT-SP-0.750-12/25
975243-016........MTL30-PMT-FD-0.750-16/30
