COUPLING STROMAG COMPENSATING FLEXIBLE TT/NA SERIES
Gambar Produk
COUPLING STROMAG COMPENSATING FLEXIBLE TT/NA SERIES
Update Terakhir
13-09-2016
Dilihat Sebanyak
199 kali
Lokasi
DKI Jakarta - Jakarta Timur
Harga
Kontak Kami
Bagikan
+ Penawaran
Perhatian!
Perusahaan ini terdaftar sebagai Free Member. Hindari melakukan pembayaran sebelum bertemu penjual atau melihat barang secara langsung. COD (Cash On Delivery) atau bertemu langsung dengan penjual merupakan metode transaksi lebih aman.
Spesifikasi COUPLING STROMAG COMPENSATING FLEXIBLE TT/NA SERIES
DESCRIPTION
Features
Highly flexible rubber-fabric couplings
Torque range 25-15,000 Nm
Precise workmanship for long service life
ATEX certification
Function & application
Highly flexible rubber-fabric couplings compensating for shaft displacements; shaft-shaft, flange-shaft for radial, axial, and angular displacements
GKN Stromag Periflex® shaft couplings are designed specifically for use in steel mills, high capacity cranes, and roller conveyor drives. Other application fields are general machinery; the building machinery, mining, and paper machinery industries; shipbuilding; and plant construction.
COUPLING SIZE .......TYRE
86 R........................................201R
86 X.........................................210X
104 R.......................................203R
104 X........................................203X
136 R........................................206R
136 X.........................................206X
178 R.........................................210R
178 X..........................................210X
211 R.........................................214R
211 X.........................................214R
263 R.........................................218 R
263 X..........................................418 X
310 R.........................................222 R
310 X..........................................411 X
370 R..........................................225 R
370 X..........................................225 X
402 R..........................................426 R
402 X...........................................426 X
450 R...........................................828 R
450 X ..........................................828 X
550 R..........................................1230 R
550 X...........................................1230 X
700 R...........................................1832 R
700 X............................................1832 X
Features
Highly flexible rubber-fabric couplings
Torque range 25-15,000 Nm
Precise workmanship for long service life
ATEX certification
Function & application
Highly flexible rubber-fabric couplings compensating for shaft displacements; shaft-shaft, flange-shaft for radial, axial, and angular displacements
GKN Stromag Periflex® shaft couplings are designed specifically for use in steel mills, high capacity cranes, and roller conveyor drives. Other application fields are general machinery; the building machinery, mining, and paper machinery industries; shipbuilding; and plant construction.
COUPLING SIZE .......TYRE
86 R........................................201R
86 X.........................................210X
104 R.......................................203R
104 X........................................203X
136 R........................................206R
136 X.........................................206X
178 R.........................................210R
178 X..........................................210X
211 R.........................................214R
211 X.........................................214R
263 R.........................................218 R
263 X..........................................418 X
310 R.........................................222 R
310 X..........................................411 X
370 R..........................................225 R
370 X..........................................225 X
402 R..........................................426 R
402 X...........................................426 X
450 R...........................................828 R
450 X ..........................................828 X
550 R..........................................1230 R
550 X...........................................1230 X
700 R...........................................1832 R
700 X............................................1832 X
